ICPDAS DN-8K16P16R
SKU
DN-8K16P16R
16-channel digital Input Terminal and 16-channel Relay Output Board
● 37-pin D-sub connector to quickly link to a I-8042W or I-87042W
● 16 Form A Signal Relay
● 16 LEDs to display the state of individual relays
● Screw terminals for field wiring
● Power Input: +12 ~ +30 VDC
● Operating temperatures: -25 ~ +75°C
● DIN-Rail mounting for industrial usage
16-channel digital Input Terminal and 16-channel Relay Output Board
Meer informatie
Art.nr.
DN-8K16P16R
Fabrikant
ICPDAS
Special
| Contact Arrangement | SPST-NO (1 form A) | ||
| Max. Switching Voltage | 125V DC, 270V AC Rated | ||
| Contact Current | 3A | ||
| Max. Contact Current | 5A | ||
| Max. Contact Capacity | 1250VA, 150W | ||
| Operate Time (typical) | 6 ms | ||
| Release Time (typical) | 3 ms | ||
| Resistive Load |
|
||
| Mechanically | 20.000.000 ops. At no load. (300 ops./minute) | ||
| Power Input | Range from +12 to +30V DC | ||
| Power Consumption | +24V @0.25A. Ma | ||
| Dimensions | 118 x 174mm | ||
| Operating Temperature | -25 °C ~ +75 °C | ||
| Storage Temperature | -30 °C ~ +80 °C | ||
| Humidity | 10% to 90%; noncondensing |
