ICPDAS M-7067D
Levertijd:
2~7 dagen
SKU
M-7067D
7-channel Relay Output Module with LED Display
● Relay output: 7 Form A
● Contact rating:
AC: 120 V @ 0.5 A
DC: 24 V @ 2 A
The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
Meer informatie
Art.nr.
M-7067D
Fabrikant
ICPDAS
Relay Output
| Channels | 7 | ||
| Relay Type | Form A relay SPST (N.O.) | ||
| Contact Rating |
|
||
| Operating Time (Max.) | 5 ms | ||
| Release Time (Min.) | 2 ms | ||
| Surge Strength | 1500 VAC | ||
| Life Time |
|
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
LED Indicators
| 1 LED as Power/Communication indicator |
| 7 LEDs as Relay Output indicators |
Protocol
| Support Modbus and DCON Protocol | Yes |
Power
| Input Voltage Range | 10 ~ 30 VDC |
| Power Consumption | 2.2 W (max.) |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 5 ~ 95%, non-condensing |
