ICPDAS 24V/1A power supply ( DIN-Rail mount ) DIN-KA52F

Levertijd:
Uit voorraad leverbaar
SKU
DIN-KA52F

24 V/1.04 A, 25 W Power Supply with DIN-Rail Mounting



● Universal input voltage
● 3 pole AC inlet IEC320-C14
● Class power (with earth pin)
● Protections: Short circuit / Overload / Overvoltage
● PWM 3842 control circuit and regulated
● Approvals: UL / CUL / TUV / BSMI / CB / FCC / CE



Derating Curve  Static Characteristics
https://fieldworks.nl/media/imageproducts/icpdas/KA-52F-48_01.gif
https://fieldworks.nl/media/imageproducts/icpdas/KA-52F-48_02.gif
Meer informatie
Art.nr.
DIN-KA52F
Fabrikant
ICPDAS
Input
Voltage Range 100 ~ 250 VAC
Frequency 50/60 Hz
Input Current 40 A / 230 VAC
LEAKAGE CURRENT (max.) 0.75 mA / 240 VAC
Output
Voltage 24 VDC
Output Current 1.04 A
Ripple 180 mVp-p
Overvoltage Protection Yes (clamp by Zener diode)
Overcurrent Protection
130 ~ 180% rated output power
Protection type: Hiccup mode, recovers automatically after fault condition is removed
Overload Protection
105 ~ 135% rated output voltage
Protection type: Recovers automatically after fault condition is removed
Temperature Coefficient ±0.04%/°C (0 ~ 50 °C)
Efficiency 82% (Typical)
Hold-up Time 16 ms at full load
Line Regulation ±1% (Line regulation is measured from low line to high line at rated load)
Load Regulation ±2% (Load regulation is measured from 20% to 100% rated load)
Safety & EMC
Safety Standards UL60950-1, CSA C22.2, TUV EN60950-1, BSMI CNS14336 approved
Withstand Voltage
I/P-O/P: 3 KVAC
I/P-FG:1.5 KVAC
Isolation Resistance I/P-O/P, I/P-FG:100 MΩ / 500 VDC / 25 / 70% RH
EMI Conduction & Radiation Compliance to EN55022 class B, FCC PART 15 / CISPR22 class B, CNS13438 class B
Harmonic Current Compliance to EN61000-3-2,3
EMS IMMUNITY Compliance to EN61000-4-2,3,4,5,6,11, light industry level, criteria A
Algemeen
MTBF 500 Khrs min. MIL-HDBK-217F (25 °C)
Omgeving
Operating Temperature 0 °C ~ +50 °C
Storage Temperature -20 °C ~ +85 °C
Humidity 20% ~ 90% RH, non-condensing
Derating Derated from 100% at +38 °C
