ICPDAS M-7061

Levertijd:
2~7 dagen
SKU
M-7061

12-channel Relay Output Module

● Support Relay Outputs
● 4 kV ESD Protection
● 3750 Vrms Intra-Module Isolation
● Operating Temperature Range: -25 °C ~ +75 °C

The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.



ICPDAS Power Relay Module M-7061D offers 12 channels for relay output. All of its channels are Form A type relay. M-7061D has 12 LED indicators for channel status as well as qualification for 4 kV ESD protection and 3750 Vrms intra-module isolation.



APPLICATIONS:

● Industrial Automation
● Industrial Machinery
● Building Automation
● Food & Beverage
● Semiconductor Fabrication
● Control system

Meer informatie
Art.nr.
M-7061
Fabrikant
ICPDAS
Relay Output
Output Channels 12
Output Type Power Relay, Form A ( SPST N.O.)
Contact Rating
250 VAC@5 A
30 VDC@5 A
Operating Time 6 ms
Release Time 3 ms
Zero Drift ±20 μV/°C
Span Drift ±25 ppm/°C
Electrical Life (Resistive Load)
VDE: 5 A@250 VAC 30,000 ops (10 ops/minute) at 75 °C
5 A@30 VDC 70,000 ops (10 ops/minute) at 75 °C
UL: 5 A@250 VAC/30 VDC 6,000 ops
3 A@250 VAC/30 VDC 100,000 ops
Mechanical Life 20,000,000 ops. at no load (300 ops./minute)
Intra-module Isolation, Field to Logic 3750 Vrms
Interface
Interface RS-485
Format N, 8, 1
Baud Rate 1200 ~ 115200 bps
LED Indicators
1 LED Power/Communication indicator
12 LEDs Relay Output indicators
Protocol
Support Modbus and DCON Protocol Yes
EMS Protection
ESD Protection ±4 kV Contact for each terminal, and ±8 kV Air for random point
EFT Protection ±4 kV to Power
Surge Protection ±3 kV for Power Input
Power
Input Voltage Range 10 ~ 30 VDC
Power Consumption 1.7 W (max.)
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +85 °C
Humidity 5 ~ 95%, non-condensing
