ICPDAS M-7067

Levertijd:
2~7 dagen
SKU
M-7067

7-channel Relay Output Module

● Relay output: 7 Form A
● Contact rating:
   AC: 120 V @ 0.5 A
   DC: 24 V @ 2 A

The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC.It has the same form factor as the I-7000 series.

Meer informatie
Art.nr.
M-7067
Fabrikant
ICPDAS
Relay Output
Channels 7
Relay Type Form A relay SPST (N.O.)
Contact Rating
AC 120 V@0.5 A
DC 24 V@1 A
Operating Time (Max.) 5 ms
Release Time (Min.) 2 ms
Surge Strength 1500 VAC
Life Time
Mechanical: 20 X 10^6 OPS
Electrical: 100 X 10^3 Full Load
Interface
Interface RS-485
Format N, 8, 1
Baud Rate 1200 ~ 115200 bps
LED Indicators
1 LED Power/Communication indicator
Protocol
Support Modbus and DCON Protocol Yes
Power
Input Voltage Range 10 ~ 30 VDC
Power Consumption 1.5 W (max.)
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +85 °C
Humidity 5 ~ 95%, non-condensing
