PoE Ethernet I/O Module with 6-ch AI, 2-ch AO, 2-ch DI, 2-ch DO

● PoE Ethernet Options
● Built-In Web Server
● Web HMI
● Modbus/TCP, Modbus/UDP Protocol
● Communication Security
● Dual Watchdog
● Operating Temperature: -25 °C ~ +75 °C
● I/O Pair Connection
● Built-In I/O (AI: 6 Channels, AO: 2 Channels, DI/Counter: 2 Channels, DO: 2 Channels)

The ET-7000 series is a family of Internet/Ethernet data acquisition and control modules that support Modbus/TCP protocols and it is an Ethernet remote I/O module with the built-in web server that used for all configuration and I/O data monitoring and controlling using a regular web browser.

Besides, with the web HMI function, no more programming or HTML skills are required; creating dynamic and attractive web pages for I/O monitoring and I/O control would be fun to engineers ever after. The ET-7000/PET-7000 offers easy and safe access for users from anytime and anywhere! In addition, the ET-7000/PET-7000 also supports Modbus/TCP protocol that makes perfect integration to SCADA software.

Furthermore, PET-7000 features "PoE" that not only data but also power is carried through an Ethernet cable. This feature makes installation of PET-7000 a piece of cake. Imagine that no more unnecessary wires, only an Ethernet cable takes care of everything in the field.

The PET-7026 is a multi-function module, there are 6-channel analog inputs, 2-channel analog output, 2-channel digital inputs and 2-channel digital outputs module. It provides programmable input range on all analog inputs (±500 mV, ±1 V, ±5 V, ±10 V, ±20 mA, 0 ~ 20 mA and 4 ~ 20 mA), analaog outputs are 12 bit with ±5 V, ±10 V, 0 ~ 20 mA and 4 ~ 20 mA and digital output can be set alarm output. Each analog input is allowed to configure an individual range and has 240 Vrms high overvoltage protection. Jumper selectable for voltage or current of inputs/outputs.



● Built-in Web Server
● Factory Automation
● Machine Automation
● Remote Maintenance
● Remote Diagnosis
● Testing Equipment.

Meer informatie
Built-In Web Server Yes
Web HMI Yes
I/O Pair Connection Yes
Ethernet Port 10/100 Base-TX with Auto MDI/MDI-X
Protocol Modbus/TCP, Modbus/UDP
Security ID, Password and IP Filter
Dual Watchdog Yes, Module (0.8 second), Communication (Programmable)
Analog Input
Input Channels 6 (Differential)
Sensor Type
±500 mV, ±1V, ±5 V, ±10 V
+ 0 mA ~ + 20 mA, ±20 mA, 4 ~ 20 mA (jumper selectable)
Individual Channel Configuration Yes
Normal Mode 16-bit
Fast Mode 12-bit
Sampling Rate
Normal Mode 10 Samples/Sec. (Total)
Fast Mode 60 Samples/Sec. (Total)
Normal Mode ±0.1%
Fast Mode ±0.5% or better
Zero Drift ±20 μV/°C
Span Drift ±25 ppm/°C
Overvoltage Protection 240 Vrms
Input Impedance 2 MΩ
Common Mode Rejection 86 dB Min.
Normal Mode Rejection 100 dB
Analog Output
Output Channels 2
Output Type + 0 VDC ~ + 5 VDC, ±5 VDC, + 0 VDC ~ + 10 VDC, ±10 VDC, + 0 mA ~ + 20 mA, + 4 mA ~ + 20 mA (jumper selectable)
Individual Channel Configuration Yes
Resolution 12-bit
Accuracy ±0.1% of FSR
Voltage Output Capability 20 mA @ 10 V
Current Load Resistance 500 Ω
Open Wire Detection Yes, for 4 ~ 20 mA only
Power On Value Yes, Programmable
Safe Value Yes, Programmable
Digital Input/Counter
Input Channels 2
Dry Contact
On Voltage Level Close to GND
Off Voltage Level Open
Effective Distance
for Dry Contact
500M max.
Wet contact
On Voltage Level + 1 VDC max.
Off Voltage Level + 3.5 VDC ~ + 30 VDC
Channels 2
Max. Counts 4,294,967,285 (32-bit)
Max. Input
100 Hz
Min. Pulse Width 5 ms
Overvoltage Protection 30 VDC
Digital Output
Output Channels 2
Type Isolated Open Collector (Sink)
Max. Load Current 700 mA/Channel
Load Voltage + 5 VDC ~ + 50 VDC
Overvoltage Protection 60 VDC
Overload Protection 1.4 A
Short-circuit Protection Yes
Power On Value Yes, Programmable
Safe Value Yes, Programmable
2-Way Isolation
Ethernet -
I/O 2500 VDC
EMS Protection
ESD (IEC 61000-4-2) 4 kV Contact for each terminal and 8 kV Air for random point
EFT (IEC 61000-4-4) ±4 kV for Power
LED Indicators
LED 1 System Running
LED 2 Ethernet Link/Act
LED 3 Ethernet 10/100 M Speed
LED 4 PoE Power
Reverse Polarity Protection Yes
Powered from Terminal Block Yes, 12 ~ 48 VDC
Powered from PoE Yes, IEEE 802.3af, Class1
Consumption 4.2 W
Dimensions (w x l x d) 72 x 123 x 35mm
Installation DIN-Rail or Wall Mounting
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -30 °C ~ +80 °C
Humidity 10 ~ 90% RH, non-condensing
