ICPDAS MDR-20-24

Levertijd:
2~7 dagen
SKU
MDR-20-24

24 W Single Output Industrial DIN-Rail Power Supply

● Universal AC input/Full range
● Protections: Short circuit / Overload / Overvoltage
● Cooling by free air convection
● Can be installed on DIN rail TS-35/7.5 or 15
● NEC class 2 / LPS compliant
● Built in DC OK active signal
● DC OK relay contact
● No load power consumption <0.75 W
● 100% full load burn-in test
● 3 years warranty

Notes:



1. All parameters NOT specially mentioned are measured at 230 VAC input, rated load and 25 of ambient temperature.

2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1 uf & 47 uf parallel capacitor.

3. Tolerance: includes set up tolerance, line regulation and load regulation.

4. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives.

5. Length of set up time is measured at first cold start. Turning ON/OFF the power supply may lead to increase of the set up time.







Derating Curve  Output Derating VS Input Voltage
https://fieldworks.nl/media/imageproducts/icpdas/mdr-20-24_02.jpg https://fieldworks.nl/media/imageproducts/icpdas/mdr-20-24_03.jpg
Meer informatie
Art.nr.
MDR-20-24
Fabrikant
ICPDAS
Input
Voltage Range
85 ~ 264 VAC
120 ~ 370 VDC
Frequency Range 47 ~ 63 Hz
Efficiency (Typical) 84%
AC Current (Typical)
0.55 A/115 VAC
0.35 A/230 VAC
Inrush Current (Typical)
COLD START 20 A/115 VAC
40 A/230 VAC
Leakage Current <1 mA / 240 VAC
Output
DC Voltage 24 VDC
Rated Current 1 A
Current Range 0 ~ 1 A
Rated Power 24 W
Ripple & Noise (max.) 150 mVp-p
Voltage ADJ. Range 21.6 ~ 26.4 V
Voltage Tolerance ±1.0%
Line Regulation ±1.0%
Load Regulation ±1.0%
Setup, Rise Time
50 ms/230 VAC
0 ms/115 VAC at full load
Hold-up Time
85 ~ 264 VAC
120 ~ 370 VDC
Protection
Overload
105 ~ 160% rated output power
Protection type: Constant current limiting, recovers automatically after fault condition is removed
Overvoltage
27.6 ~ 32.4 V
Protection type: Shut down o/p voltage, re-power on to recover
Function
DC OK Active Signal (max.) 18 ~ 27 V/20 mA
Safety & EMC
Safety Standards UL508, TUV EN60950-1 approved, NEC class 2 / LPS compliant
Withstand Voltage
I/P-O/P 3 KVAC
I/P-FG 1.5 KVAC
O/P-FG 0.5 KVAC
Isolation Resistance
I/P-O/P 100 MΩ/500 VDC
I/P-FG
O/P-FG
EMI Conduction & Radiation Compliance to EN55011, EN55022 (CISPR22), EN61204-3 Class
Harmonic Current Compliance to EN61000-3-2,-3
EMS Immunity Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11, ENV50204, EN55024, EN61000-6-1, EN61204-3, light industry level, criteria A
Algemeen
MTBF
236.9K hrs min.
MIL-HDBK-217F (25°C )
Omgeving
Operating Temperature -20 °C ~ +70 °C (Refer to output load derating curve)
Operating Humidity 20 ~ 90% RH non-condensing
Storage Temperature -40 °C ~ +85 °C
Storage Humidity 10 ~ 95% RH
Temperature Coefficient ±0.03%/°C (0 ~ 50 °C)
Vibration Component:10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes; Mounting: Compliance to IEC60068-2-6
Mechanical
Dimensions (w x h x d): 22.5 x 90 x 100mm
