ICPDAS NS-205PSE - Unmanaged PoE Ethernet Switch

Levertijd:

Uit voorraad leverbaar

SKU

NS-205PSE

● Automatic MDI/MDI-X crossover for plug-and-play
● Each port supports both 10/100 Mbps speed auto negotiation
● Store-and-forward architecture● Full duplex IEEE 802.3x and half duplex backpressure flow control
● 3.2Gbps high performance memory bandwidth
● Power Inputs +46 ~ +55 VDC
● Supports operating temperatures from -40 °C ~ +75 °C
● DIN-Rail mountable
● IEEE 802.3af Compliant PoE Ports

Brochure EN

Details

The NS-205PSE is a 5-port unmanaged PoE (Power-over-Ethernet) Industrial Ethernet switch, it supports 4 PoE ports which are classified as power source equipments (PSE).

The NS-205PSE makes centralized power supply come true and provides up to 15.4 watts of power per port. The NS-205PSE can be used to power IEEE802.3af compliant powered devices (PD) by Ethernet cable and eliminates the need for additional power wiring.

SPECIFICATIES

Meer informatie

Art.nr.

NS-205PSE

Fabrikant

ICPDAS

Technology

Standards	IEEE 802.3, 802.3u, 802.3x ,802.3af (Power over Ethernet)
Processing Type	Store & forward, wire speed switching
MAC Addresses	1024
Memory Bandwidth	3.2 Gbps
Frame buffer memory	512 Kbit
Flow Control	IEEE802.3x flow control, back pressure flow control

Interface

RJ45 ports

10/100 Base-TX auto negotiation speed, F/H duplex mode,
and auto MDI/MDI-X connection

LED Indicators

Power, 10/100M, Link/Act

Ethernet Isolation

1500Vrms 1 minute

Frame Ground for EMS Protection

Yes

Cable

Ethernet: 2-pair UTP/STP Cat.3,4,5, EIA/TIA-568 100-ohm

Fast Ethernet: 2-pair UTP/STP Cat. 5, EIA/TIA-568 100-ohm

Power Input

Input Voltage Range	+46 ~ +55VDC for PoE output
Power consumption	1.3A@48VDC, ±5% arrowed
Protection	Power reverse polarity protection
Frame Ground for EMS Protection	Yes
Connection	3-Pin Removable Terminal Block

PoE Output

Compliance	100% IEEE 802.3af compliant
Classification	PSE (Power Sourcing Equipment)
Voltage	+46 ~ +48 VDC depending on power input
Power	Up to 15.4 watts per channel
Operation	Automatic detection and power management
