ICPDAS PET-7253
Levertijd:
2~7 dagen
SKU
PET-7253
PoE Ethernet I/O Module with 2-port Ethernet Switch and 16 Digital Inputs / Counter
● Built-in Web Server
● Web HMI
● Support for both Modbus TCP and Modbus UDP Protocols
● Communication Security
● Dual Watchdog
● Wide Operating Temperature Range: -25 ~ +75°C
● I/O Pair Connection
● 16 channel Digital in / Counter
The PET-7253 provides 16 dry contact digital input channels. Each input channel can be used as a 32-bit counter. It features optical isolation for 3750 Vrms of transient overvoltage protection but doesn’t provide channel-to-channel isolation. It can safely be used in applications where hazardous voltages are present.
Meer informatie
Art.nr.
PET-7253
Fabrikant
ICPDAS
Software
| Built-In Web Server | Yes |
| Web HMI | Yes |
| I/O Pair Connection | Yes |
Communication
| Ethernet Port | 10/100 Base-TX with Auto MDI/MDI-X |
| Protocol | Modbus/TCP, Modbus/UDP |
| Security | ID, Password and IP Filter |
| Dual Watchdog | Yes, Module (0.8 seconds), Communication (Programmable) |
Digital Input/Counter
| Digital Input/Counter | |||
| Channels | 16 | ||
| Contact | Dry Contact | ||
| Sink/Source (NPN/PNP) | Source | ||
| On Voltage Level | Close to GND | ||
| Off Voltage Level | Open | ||
| Counters | Max. Count | 4,294,967,285 (32 bits) | |
| Max. Input Frequency | 100 Hz | ||
| Min. Pulse Width | 5 ms | ||
| Overvoltage Protection | - | ||
| Effective Distance | 500 M Max. | ||
2-Way Isolation
| Ethernet | - |
| I/O | 2500 VDC |
EMS Protection
| ESD (IEC 61000-4-2) | 4 kV Contact for each terminal and 8 kV Air for random point |
| EFT (IEC 61000-4-4) | ±4 kV for Power |
| Surge (IEC 61000-4-5) | ±4 kV for Power |
LED Indicators
| L1 | System Running |
| L2 | Ethernet Link/Act |
| L3 | Ethernet 10/100 M Speed |
Power
| Reverse Polarity Protection | Yes |
| Powered from Terminal Block | Yes, 12 ~ 48 VDC |
| Powered from PoE | Yes, IEEE 802.3af, Class1 |
| Consumption | 4.1 W |
Mechanical
| Dimensions (w x l x h) | 76 x 120 x 38mm |
| Installation | DIN-Rail or Wall Mounting |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
