ICPDAS M-7017
Levertijd:
2~7 dagen
SKU
M-7017
8-channel Analog Input Module
● Input Channels: 6 differential and 2 single-ended or 8 differntial (jumper selectable)
● Input Types: mV, V, mA (requires optional external 125 Ω resistor)
● Input Ranges: ±150 mV, ±500 mV, ±1 V, ±5 V, ±10 V, ±20 mA
● Sampling Rate: 10 samples/sec. total
The ICPDAS Analog Input Module M-7017 is a data acquisition and control module that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
Meer informatie
Art.nr.
M-7017
Fabrikant
ICPDAS
Analog Input
| Input Channels | 8 differential | ||
| Input Type |
|
||
| Resolution | 16-bit | ||
| Sampling Rate | 10 samples/sec. | ||
| Accuracy | ±0.1% | ||
| Bandwidth | 15.7 Hz | ||
| Zero Drift | ±20 uV/°C | ||
| Span Drift | ±25 ppm/°C | ||
| Input Impedance | 20 MΩ | ||
| Common Mode Rejection | 86 dB min | ||
| Normal Mode Rejection | 100 dB | ||
| Overvoltage Protection | ±35 V (P-P) | ||
| Intra-module Isolation, Field to Logic | 3000 VDC |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
LED Indicators
| 1 LED | Power/Communication indicator |
Protocol
| Support Modbus and DCON Protocol | Yes |
Power
| Input | +10 ~ +30 VDC |
| Power Consumption | 1.3 W |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 5 ~ 95%, non-condensing |
