ICPDAS M-7017RC

Levertijd:
2~7 dagen
SKU
M-7017RC

8-channel Current Input Module with High Common Voltage Protection

● Input channels: 8 differential
● Input Types: Only Current Input (±20mA)
● Sampling Rate: 10/60 samples/sec total
● -3dB Bandwith: 15.7 Hz.
● Accuracy: ±0.1%
● Common Mode Rejection: Typical 86 dB
● Voltage Imput Impedance: >2 MΩ
● Overvoltage Protection: 240 Vrms
● Isolation Voltage: 3000 Vrms

The ICPDAS Analog Input Module M-7017RC is a data acquisition and control module that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.

Meer informatie
Art.nr.
M-7017RC
Fabrikant
ICPDAS
Analog Input
Input Channels 8 differential
Input Type ±20 mA, 0 ~ 20 mA, 4 ~ 20 mA
Resolution 16-bit (Normal Mode) / 12-bit (Fast Mode)
Sampling Rate 10 samples/sec. (Normal Mode) / 60 sample/sec. (Fast Mode)
Accuracy ±0.1% (Normal Mode) / ±0.5% (Fast Mode) or better
Bandwidth 15.7 Hz (Normal Mode) / 78.7 Hz (Fast Mode)
Zero Drift ±20 uV/°C
Span Drift ±25 ppm/°C
Input Impedance 125 Ω
Common Mode Rejection 86 dB min.
Normal Mode Rejection 100 dB
Common Voltage ±200 VDC
4KV ESD Protection Yes, Contact for each terminal.
Intra-module Isolation, Field to Logic 3000 VDC
Interface
Interface RS-485
Format N, 8, 1
Baud Rate 1200 ~ 115200 bps
LED Indicators
1 LED Power/Communication indicator
Protocol
Support Modbus and DCON Protocol Yes
Power
Input +10 ~ +30 VDC
Power Consumption 1.3 W
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +85 °C
Humidity 5 ~ 95%, non-condensing
