Axiomtek's rBOX series and ICO series are fanless embedded field controller solutions, specifically designed for intelligent computing and communication applications like power plant automation, intelligent transportation systems, unmanned control room and more. The rBOX series meets Safety Agency requirements and passed heavy EMI/EMS testing. Furthermore, to streamline implementation of management application, the "AXView" monitoring software package has been launched along with rBOX series for customers to build their own management systems easily and quickly.

12 artikel(en)

Robust Din-rail Fanless Embedded System with RISC-based (iMX-287) Processor 4 COM, 2 CAN Bus and DIO

● Fanless design
● RISC-based module (iMX-287) processor
● 128MB DDR2 SDRAM onboard
● 4 GB eMMC onboard
● Completed Industrial AP development software (Serial server,Modbus gateway, SNMP, Remote manager)
● Wide range DC power input (12 - 48V) with terminal block
● Ready-to-run embedded Linux operating system
● Wide temperature operation of -40°C ~ +70°C



Robust Din-rail Fanless Embedded System with RISC-based (i.MX 6) Processor 4 COM, 2 CAN Bus and DIO

● Fanless design
● RISC-based module (i.MX 6) processor
● 1 GB DDR3 SDRAM onboard
● 4 GB eMMC onboard
● Completed industrial AP development software
● Wide range DC power input (12 - 48V) with terminal block
● Ready-to-run embedded Linux operating system
● Wide temperature operation of -40°C ~ +70°C

Robust DIN-rail Fanless Embedded System with Intel® Atom™ x5-E3930 Processor, 2 COM, 1 LAN, 2 USB and 1 DIO

● Extreme cost-effective with fanless and cableless design
● Intel® Atom™ x5-E3930 processor
● 2 COM, 2 USB, 1 GbE LAN
● 8-bit programmable DIO for IoT gateway applications
● Wide operating temperature range from -20°C to +70°C
● 12-24 VDC wide range power input
● OVP, UVP, OCP, RPP power protection design
● AXView 2.0 intelligent embedded monitoring software for IoT


Robust Din-rail Fanless Embedded System with RISC-based i.MX 6UL Processor, 2 COM, 2 LANs and DIO (2-IN/1-OUT)

● RISC-based (i.MX 6UltraLite) processor 528 MHz
● 256 MB DDR3 SDRAM onboard
● 4 GB eMMC Flash onboard
● 1 Wireless (Wi-Fi or 3G/4G)
● Supports 2 digital inputs and 1 digital output
● Wide range DC power input (9 - 48V) with terminal block
● Ready-to-run embedded Linux operating system (Yocto)
● Fanless design
● Wide temperature operation of -40°C ~ +70°C

Robust DIN-rail Fanless Embedded System with Intel® Celeron® Processor N3060/N3160, 2 COM, 4 USB, 2 GbE LANs (1 PoE PD), DIO and RTC

● Fanless design
● Intel® Celeron® processor N3060 (1.6 GHz/2-core) or N3160 (1.6 GHz/4-core)
● 2 RS-232/422/485 ports
● 4 USB ports
● 2 isolated 10/100/1000 Mbps Ethernet ports
● 1 PoE PD compliant with IEEE 802.3at standard through LAN 1
● 1 DIO port
● Supports wireless (3G/GPRS & Wi-Fi)
● 1 mSATA & SATA SSD (or HDD)
● 12-24 VDC wide range power input

ATEX & CID2 Anti-Explosive Certified Robust Din-rail Fanless Embedded System with Intel® Atom™ Processor E3827 (1.75GHz)

● Fanless and cableless design
● Supports Intel® Atom™ processor E3827 (1.75GHz) Dual Core
● Wide temperature operation of -40°C ~ +70°C
● 4 isolated RS-232/422/485 ports & 2 RS-232/422/485 ports
● 2 isolated 10/100/1000Mbps Ethernet
● 2 watchdog timer
● RTC Battery function
● LED indicators
● ATEX & CID2 anti-explosive certification
● Supports one 2.5” SATA SSD/HDD (or mSATA) and CompactFlash™
● Wide range 12-48 VDC-In with terminal block
● Supports AXView 2.0 intelligent embedded monitoring software solution for IoT


Robust Din-rail Fanless Embedded System with Intel® Atom™ Processor E3815 as an Intel® IoT Gateway Solution

● Supports Intel® IoT Gateway Solution
● Fanless and robust design
● Supports Intel® Atom™ processor E3815 (1.46GHz)
● 4 RS-232/422/485 COM ports
● 2 isolated 10/100/1000Mbps Ethernet ports
● 1 wireless (3G/GPRS)
● Supports 1 CompactFlash™ (or mSATA) and SATA SSD (or HDD)
● Extended temperature range from -20°C to +70°C
● Wide range 12 - 24V DC-In
● RTC battery support


Robust Din-rail Fanless Embedded System with Intel® Atom™ Processor E3827 (1.75 GHz), 6 COM, SATA SSD, DIO, 2 GbE LANs and RTC

● Fanless and cableless design
● Supports Intel® Atom™ processor E3827 (1.75GHz) Dual Core
● Wide temperature operation of -40°C ~ +70°C
● 4 isolated RS-232/422/485 ports & 2 RS-232/422/485 ports
● 2 isolated 10/100/1000Mbps Ethernet
● 2 watchdog timer
● RTC Battery function
● LED indicators
● 3 wireless (3G/GPRS & Wifi)
● SNMP V1/V2c
● Supports 1 x 2.5" SATA SSD (or HDD)
● Supports one 2.5” SATA SSD/HDD (or mSATA) and CompactFlash™
● Wide range 12-48 VDC-In with terminal block
● Supports AXView 2.0 intelligent embedded monitoring software solution for IoT


ATEX Anti-Explosive Certified Robust Din-rail Fanless Embedded System with Intel® Atom™ Processor Z510PT/ Z520PT up to 1.33 GHz, Intel® US15WPT Chipset, 6 Isolated COM and 1 Isolated DIO

● ATEX Anti-Explosive Type "ic" Zone 2 Group II Certification
● Fanless and cableless design
● Supports Intel® Atom™ processor Z510 PT 1.1 GHz or Z520 PT 1.33 GHz
●  Wide temperature operation of -40°C ~ +70°C
● 6 isolated COM ports, 1 isolation DIO (4-IN/4-OUT)
● 2 isolated Ethernet
● 2 watchdog timer
● LED indicators
● SNMP V1/V2c
● Supports one CompactFlash™, one SD card (optional)
● 2 power paths with terminal block and 12-48VDC
● Supports AXView monitoring software package

Robust DIN-Rail Fanless Embedded System with AMD LX800 + CS5536AF and 6 Isolated COM

● Fanless operation
● Wide temperature operation of -40 °C ~ +70 °C
● Supports 6 isolated COM ports, 2 USB ports, 1 DIO (4 in/out), VGA port
● Supports two 10/100Mbps Ethernet with Magnetic Isolation Protection
● SNMP V1/V2c
● Support CompactFlash™
● Redundant power input with terminal block and 12 ~ 48 VDC
● Supports AXView monitoring software package

DIN-Rail Fanless Embedded System with AMD LX800 + CS5536AF and 4 Isolated COM

● Fanless operation
● Wide temperature operation of -40 °C ~ +70 °C
● Supports 4 isolated COM ports, 2 USB ports, VGA port
● Supports two 10/100Mbps Ethernet with Magnetic Isolation Protection
● SNMP V1/V2c
● Supports CompactFlash™
● Redundant power input with terminal block and 12 ~ 48 VDC
● Supports AXView monitoring software package

Robust DIN-rail Fanless Embedded System with AMD LX800 + CS5536AF and 4-port PoE

● Fanless operation
● Wide temperature operation of -40°C ~ +70°C
● Supports 4-port IEEE802.3af Power over Ethernet (PoE) Power Sourcing Equipment (PSE)
● Supports 2 COM ports, 2 USB ports and VGA port
● Supports one 10/100Mbps Ethernet with Magnetic Isolation Protection
● SNMP V1/V2c
● Supports CompactFlash™
● Redundant power input with terminal block and 48VDC
● Supports AXView monitoring software package
