ICPDAS M-7003
8-channel AI and 4-channels Relay Output Module
● Voltage and Current Inputs
● ±240 Vrms Overvoltage Protection
● High Resolution: 16-bit
● 2500 VDC Intra-Module Isolation
● Sink and Source Type Digital Inputs
● Photocouple Isolation
● Support Relay Outputs
● DIN-Rail Mountable
● Dual Watchdog
● Operating Temperature Range: -25 °C ~ +75 °C
The ICPDAS Relay Output Module M-7003 is a 16-bit, 4-channel differential analog inputs 5-channel digital inputs and 4-channels for relay output. All of its channels are Form A type relay module that provides programmable input range on all analog channels (±150 mV, ±500 mV, ±1 V, ±5 V, ±10 V, ±20 mA, 0 ~ 20 mA and 4 ~ 20 mA) and digital output can be set alarm output with shortcircuit protection and overload protection. Each analog channel is allowed to configure an individual range and has 240 Vrms high overvoltage protection. Jumper selectable for voltage or current input. The sampling rate of ICPDAS Relay Output Module M-7003 is changeable; there are fast mode and normal mode for your consideration. M-7003 also has qualification for 4 kV ESD protection as well as 2500 VDC intra-module isolation.
Applications:
● Building Automation
● Factory Automation
● Machine Automation
● Remote Maintenance
● Remote Diagnosis
● Testing Equipment
| Channel | 8 | ||||
| Wiring | 5-channel differential and 3-channel single-ended | ||||
| Input Range |
|
||||
| Resolution | 12/16-bit | ||||
| Accuracy |
|
||||
| Sampling Rate |
|
||||
| Input Impedance |
|
||||
| Common Voltage Protection | ±15 VDC | ||||
| Individual Channel Configuration | - | ||||
| Overvoltage Protection | 120 VDC |
| Channel | 4 | ||
| Type | Power Relay (Form A) | ||
| Contact Rating |
|
||
| Surge Strength | 3000 VDC | ||
| Operate Time | 3 ms | ||
| Release Time | 2 ms | ||
| Mechanical Endurance | 2 × 107 ops. | ||
| Electrical Endurance | 105 ops. | ||
| Power-on Value | Yes | ||
| Safe Value | Yes |
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
| Protocol | DCON Modbus/RTU |
| Dual Watchdog | Yes, Module (1.6 Seconds), Communication (Programmable) |
| System LED Indicator | Yes, 1 LED as Power/Communication Indicator |
| I/O LED Indicator | N/A |
| 7-Segment LED Display | Yes |
| Intra-Module Isolation, Field-to-Logic | 2500 VDC |
| ESD (IEC 61000-4-2) | ±4 kV |
| EFT (IEC 61000-4-4) | ±4 kV |
| Surge (IEC 61000-4-5) | ±3 kV |
| Reverse Polarity Protection | Yes |
| Input Voltage Range | 10 ~ 30 VDC |
| Consumption | 1.8 W |
| Dimensions (w x l x h) | 72 x 123 x 35 mm |
| Installation | DIN-Rail or Wall Mounting |
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 10 ~ 95% RH, Non-condensing |
