ICPDAS WISE-7102

Levertijd:

2~7 dagen

SKU

WISE-7102

3-Channel Analog Inputs, 6-Channel Digital Inputs and 3-Channel Power Relay Outputs PoE Module

● Built-in Web Server for IF-THEN-ELSE rule setting
● Built-in IF-THEN-ELSE rule enigne for logic operation
● No more programming. Just click and get done!
● Support IO, Counter, Timer, Email operations
● Modbus/TCP Protocol for SCADA Software Seamless Integration
● IEEE 802.3af-compliant Power over Ethernet (PoE)
● 10/100 Base-TX Ethernet
● AI: 3-channel (mV, V, mA)
● DO: 3-channel (Power Relay, Form A)
● DI: 6-channel (Wet)

Brochure EN

Details

WISE (Web Inside, Smart Engine) is a product series developed by ICP DAS that functions as control units for use in remote logic control and monitoring in various industrial applications. WISE offers a user-friendly and intuitive web site interface that allows users to implement IF-THEN-ELSE control logic on controllers just a few clicks away; no programming is required. With its powerful and easy-to-use features, it will minimize the learning curve, shorten time to market and dramatically reduce the effort and cost spent on system development.

WISE-7102 follows IEEE 802.3af-compliant (classification, Class 1) Power over Ethernet (PoE) specification. It allows receiving power from PoE enabled network by Ethernet pairs (Category 5 Ethernet cable). This feature provides greater flexibility and higher efficiency therefore simplifying systems design, saving space, reducing cables and eliminating the requirement for dedicated electrical outlets. Meanwhile, in case under a non-PoE environment, WISE-7102 will still be able to receive power from auxiliary power sources like AC adapters or battery, etc.

This multi-function module WISE-7102 supports Modbus/TCP protocol to make seamless integration with SCADA software available. It features 3-channel analog inputs, 6-channel digital inputs and 3-channel Power Relay outputs. Each analog input channel provides 240 Vrms high over voltage protection.

APPLICATIONS:

● Building Automation
● Factory Automation
● Machine Automation
● Remote Maintenance
● Remote diagnosis and Testing Equipment

SPECIFICATIES

Meer informatie

Art.nr.

WISE-7102

Fabrikant

ICPDAS

Analog Input

Input Channels		3 (Differential)
Input Type		+/-150 mV, +/-500 mV, +/-1V, +/-5 V, +/-10 V
(Jumper Selectable)		+0 mA ~ +20 mA, +/-20 mA, 4 ~ 20 mA
Resolution		16-bit
Sampling Rate		10 Samples/Sec.
Accuracy		+/-0.1%
Zero Drift		+/-20 uV/°C
Span Drift		+/-25 ppm/°C
Overvoltage Protection		240 Vrms
Input Impedance	Voltage	2M Ω
	Current	125 Ω
Common Mode Rejection		86 dB Min.
Normal Mode Rejection		100 dB
Individual Channel Configuration		Yes
Open Wire Detection		Yes, for 4 ~ 20 mA only

Digital Input

Input Channels		6
Input Type		Wet Contact
Sink/Source (NPN/PNP)		Sink/Source
On Voltage Level		+10 VDC ~ +50 VDC
Off Voltage Level		+4 VDC Max.
Input Impedance		10 KΩ, 0.5W
Counters	Channels	6
	Max. Counts	16-bit (65535)
	Max. Input Frequency	50 Hz
	Min. Pulse Width	10 ms
Overvoltage Protection		+50 VDC

Relay Output

Channels		3
Type		Power Relay, Form A (SPST N.O.)
Operating Voltage Range		250 VAC/30 VDC
Max Load Current		5.0A/channel at 25°C
Operate Time		6 ms (Typical)
Release Time		3 ms (Typical)
Electrical Life	VDE:	5 A @ 250 VAC 30,000 ops (10 ops/minute) at 75°C.
( Resistive load )		5 A @ 30 VDC 70,000 ops (10 ops/minute) at 75°C.
	UL:	5 A @ 250 VAC/30 VDC 6,000 ops.
		3 A @ 250 VAC/30 VDC 100,000 ops.
Mechanical Life		20,000,000 ops. at no load (300 ops./minute).
Intra-module Isolation,		3750 VDC
Field to Logic
