10-channel Thermocouple Input with High Voltage Protection and 6-channel Isolated Output PoE Module
● Built-in Web Server for IF-THEN-ELSE rule setting ● Built-in IF-THEN-ELSE rule enigne for logic operation ● No more programming. Just click and get done! ● Support IO, Counter, Timer, Email operations ● Modbus/TCP Protocol for SCADA Software Seamless Integration ● IEEE 802.3af-compliant Power over Ethernet (PoE) ● 10/100 Base-TX Ethernet ● Support Current Input, Voltage Input and Thermocouple Input ● Overvoltage Protection is up to 240 Vrms ● 6-channel Digital Outputs ● 2-way Isolation/ESD Protection
WISE (Web Inside, Smart Engine) is a product series developed by ICP DAS that functions as control units for use in remote logic control and monitoring in various industrial applications. WISE offers a user-friendly and intuitive web site interface that allows users to implement IF-THEN-ELSE control logic on controllers just a few clicks away; no programming is required. With its powerful and easy-to-use features, it will minimize the learning curve, shorten time to market and dramatically reduce the effort and cost spent on system development.
ICPDAS WISE Module WISE-7118Z follows IEEE 802.3af-compliant (classification, Class 1) Power over Ethernet (PoE) specification. It allows receiving power from PoE enabled network by Ethernet pairs (Category 5 Ethernet cable). This feature provides greater flexibility and higher efficiency therefore simplifying systems design, saving space, reducing cables and eliminating the requirement for dedicated electrical outlets. Meanwhile, in case under a non-PoE environment, WISE-7118Z will still be able to receive power from auxiliary power sources like AC adapters or battery.
This multi-function ICPDAS WISE Module WISE-7118Z supports Modbus/TCP protocol to make seamless integration with SCADA software available. It features 16-bit, 10-channel differential analog inputs and 6-channel digital ouputs. Each analog channel is allowed to configure an individual range and has 240 Vrms high overvoltage protection.
APPLICATIONS:
● Building Automation ● Factory Automation ● Machine Automation ● Remote Maintenance ● Remote diagnosis and Testing Equipment
