ICPDAS PET-7005
Levertijd:
2~7 dagen
SKU
PET-7005
8-channel Thermistor Input and 4-channel Isolated Output PoE Module
● PoE Ethernet Options
● Built-In Web Server
● Web HMI
● Modbus/TCP, Modbus/UDP Protocol
● Communication Security
● Dual Watchdog
● Operating Temperature: -25 °C ~ +75 °C
● I/O Pair Connection
● Built-In I/O (Thermistor Input: 8 Channels, DO: 4 Channels)
Power over Ethernet (PoE) allows power and data to be carried over a single Ethernet cable, so a device can operate solely from the power it receives through the data cable. This innovation allows greater flexibility in office design, higher efficiency in systems design, and faster turnaround time in set-up and implementation.
The PET-7005 feature true IEEE 802.3af-compliant (classification, Class 1) Power over Ethernet (PoE) using both Ethernet pairs (Category 5 Ethernet cable). The PET-7005 can receive power from an auxiliary power sources like AC adapters and battery in addition to the PoE enabled network. This is a desirable feature when the total system power requirements exceed the PSE's load capacity. Furthermore, with the auxiliary power option, the PET-7005 can be used in a standard Ethernet (non-PoE) system.
The PET-7005, a web-based Ethernet I/O module, features a built-in web server, which allows configuration, I/O monitoring and I/O control by simply using a regular web browser. Besides, with the web HMI function, no more programming or HTML skills are needed; creating dynamic and attractive web pages for I/O monitoring and I/O control would be fun to engineers ever after. The PET-7005 offers easy and safe access for users from anytime and anywhere! In addition, PET-7005 also supports Modbus/TCP protocol that makes seamless integration to SCADA software.
The PET-7005 is a 16-bit, 8-channel Thermistor inputs and 4-channel digital outputs module that provides programmable input range on all analog channels and digital output can be set alarm output. Each analog channel is allowed to configure an individual range.
APPLICATIONS
● Building Automation
● Factory Automation
● Machine Automation
● Remote Maintenance
● Remote Diagnosis
● Testing Equipment
Meer informatie
Art.nr.
PET-7005
Fabrikant
ICPDAS
Software
| Built-In Web Server | Yes |
| Web HMI | Yes |
| I/O Pair Connection | Yes |
Communication
| Ethernet Port | 10/100 Base-TX with Auto MDI/MDI-X |
| Protocol | Modbus/TCP, Modbus/UDP |
| Security | ID, Password and IP Filter |
| Dual Watchdog | Yes, Module (0.8 second), Communication (Programmable) |
Thermistor Input
| Input Channels | 8 Differential |
| Input Type | Precon ST-A3, Fenwell U, YSI L100, YSI L300, YSI L1000, YSI B2252, YSI B3000, YSI B5000, YSI B6000, YSI B10000, YSI H10000, YSI H30000, User-defined |
| Individual Channel Configuration | Yes |
| Resolution | 16-bit |
| Sampling Rate | 10 samples/sec. total |
| Accuracy | ±0.1 % or better |
| Zero Drift | ±20 μV/°C |
| Span Drift | ±25 ppm/°C |
| Overvoltage Protection | 110 VDC/VAC |
| Common Mode Rejection | 86 dB min. |
| Normal Mode Rejection | 100 dB |
| Open Wire Detection | Yes |
Digital Output
| Output Channels | 4 |
| Type | Isolated Open Collector (Sink) |
| Max. Load Current | 700 mA/Channel |
| Load Voltage | 5 VDC ~ 50 VDC |
| Overvoltage Protection | 60 VDC |
| Overload Protection | 1.4 A |
| Short-circuit Protection | Yes |
| Power On Value | Yes, Programmable |
| Safe Value | Yes, Programmable |
2-Way Isolation
| Ethernet | - |
| I/O | 2500 VDC |
EMS Protection
| ESD (IEC 61000-4-2) | 4 kV Contact for each terminal and 8 kV Air for random point |
| EFT (IEC 61000-4-4) | ±4 kV for Power |
LED Indicators
| LED 1 | System Running |
| LED 2 | Ethernet Link/Act |
| LED 3 | Ethernet 10/100 M Speed |
| LED 4 | PoE Power |
Power
| Reverse Polarity Protection | Yes |
| Powered from Terminal Block | Yes, 12 ~ 48 VDC |
| Powered from PoE | Yes, IEEE 802.3af, Class1 |
| Consumption | 3.0 W |
Mechanical
| Dimensions (w x l x d) | 72 x 123 x 35mm |
| Installation | DIN-Rail or Wall Mounting |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
