ICPDAS PET-7015

Levertijd:
2~7 dagen
SKU
PET-7015

7-channel RTD Input Module with 3-wire RTD lead resistance elimination PoE Module

● PoE Ethernet Options
● Built-In Web Server
● Web HMI
● Modbus/TCP, Modbus/UDP Protocol
● Communication Security
● Dual Watchdog
● Operating Temperature: -25 °C ~ +75 °C
● I/O Pair Connection
● Built-In I/O (RTD Input: 7 Channels)

Power-over-Ethernet (PoE) allows power and data to be carried over a single Ethernet cable, so a device can operate solely from the power it receives through the data cable. This innovation allows greater flexibility in office design, higher efficiency in systems design, and faster turnaround time in set-up and implementation.

The PET-7015 feature true IEEE 802.3af-compliant (classification, Class 1) Power over Ethernet (PoE) using both Ethernet pairs (Category 5 Ethernet cable). The PET-7015 can receive power from an auxiliary power sources like AC adapters and battery in addition to the PoE enabled network. This is a desirable feature when the total system power requirements exceed the PSE's load capacity. Furthermore, with the auxiliary power option, the PET-7015 can be used in a standard Ethernet (non-PoE) system.

The PET-7015, a web-based Ethernet I/O module, features a built-in web server, which allows configuration, I/O monitoring and I/O control by simply using a regular web browser. Besides, with the web HMI function, no more programming or HTML skills are needed; creating dynamic and attractive web pages for I/O monitoring and I/O control would be fun to engineers ever after. The PET-7015 offers easy and safe access for users from anytime and anywhere! In addition, PET-7015 also supports Modbus/TCP protocol that makes seamless integration to SCADA software.

The PET-7015 is a 16-bit, 7-channel RTD inputs module that provides programmable input range on all analog channels(Pt100, Pt1000, Ni120, Cu100, Cu1000). Each channel is allowed to configure an individual range that supports 3-wire RTD lead resistance elimination and open wire detection for RTD measurement.



APPLICATIONS

● Building Automation
● Factory Automation
● Machine Automation
● Remote Maintenance
● Remote Diagnosis
● Testing Equipment

Meer informatie
Art.nr.
PET-7015
Fabrikant
ICPDAS
Software
Built-In Web Server Yes
Web HMI Yes
I/O Pair Connection Yes
Communication
Ethernet Port 10/100 Base-TX with Auto MDI/MDI-X
Protocol Modbus/TCP, Modbus/UDP
Security ID, Password and IP Filter
Dual Watchdog Yes, Module (0.8 second), Communication (Programmable)
RTD Input
Input Channels 7 (Differential)
Sensor Type Pt100, Pt1000, Ni120, Cu100, Cu1000
Wire Connection 2/3 wire
Individual Channel Configuration Yes
Resolution 16-bit
Sampling Rate 12 Samples/Sec. (Total)
Accuracy +/-0.05%
Zero Drift +/-0.5 μV/°C
Span Drift +/-20 μV/°C
Common Mode Rejection 150 dB
Normal Mode Rejection 100 dB
Input Impedance >1 MΩ
Open Wire Detection Yes
3-wire RTD Lead Resistance Elimination Yes
2-Way Isolation
Ethernet -
AI and DO 2500 VDC
EMS Protection
ESD (IEC 61000-4-2) 4 kV Contact for each terminal and 8 kV Air for random point
EFT (IEC 61000-4-4) ±4 kV for Power
LED Indicators
LED 1 System Running
LED 2 Ethernet Link/Act
LED 3 Ethernet 10/100 M Speed
LED 4 PoE Power
Power
Protection Power reverse polarity protection
Reverse Polarity Protection Yes
Powered from Terminal Block Yes, 10 ~ 30 VDC
Powered from PoE Yes, IEEE 802.3af, Class 1
Consumption 2.1 W
Mechanical
Dimensions (w x l x d) 72 x 123 x 35mm
Installation DIN-Rail or Wall Mounting
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -30 °C ~ +80 °C
Humidity 5 ~ 90% RH, non-condensing
