ICPDAS PET-7244

Levertijd:

2~7 dagen

SKU

PET-7244

PoE Ethernet I/O Module with 2-port Ethernet Switch and 8 channel Digital In and 8 Digital Out

● Built-in Web Server
● Web HMI
● Support for both Modbus TCP and Modbus UDP Protocols
● Communication Security
● Dual Watchdog
● Wide Operating Temperature Range: -25 ~ +75°C
● I/O Pair Connection
● 8 channel Digital Out
● 8 channel Digital In

Details

The PET-7244, PoE Ethernet I/O Module with 2-port Ethernet Switch, provides 8 wet contact digital input channels and 8 sink-type digital output channels. It features optical isolation for 3750 Vrms of transient overvoltage protection but doesn’t provide channel-to-channel isolation.

Each input channel can be used as a 32-bit counter and each output channel can drive 300 mA load. The power-on value and safe value of digital output channel are programmable. It can safely be used in applications where hazardous voltages are present.

SPECIFICATIES

Meer informatie

Art.nr.

PET-7244

Fabrikant

ICPDAS

Software

Built-In Web Server	Yes
Web HMI	Yes
I/O Pair Connection	Yes

Communication

Ethernet Port	10/100 Base-TX with Auto MDI/MDI-X
Protocol	Modbus/TCP, Modbus/UDP
Security	ID, Password and IP Filter
Dual Watchdog	Yes, Module (0.8 seconds), Communication (Programmable)

Digital Input/Counter

Digital Input / Counter
Channels		8
Contact		Wet Contact
Sink/Source (NPN/PNP)		Sink/Source
On Voltage Level		+10 VDC ~ +50 VDC
Off Voltage Level		+4 VDC Max.
Input Impedance		10 kΩ
Counters	Max. Count	4,294,967,285 (32 bits)
	Max. Input Frequency	100 Hz
	Min. Pulse Width	5 ms
Overvoltage Protection		+70 VDC

Digital Output

Digital Output
Channels		8
Type		Isolated Open Collector
Sink/Source (NPN/PNP)		Sink
Max. Load Current		650 mA/channel at 25°C
		Direct Drive Power Relay Module
Load Voltage		+3.5 VDC ~ +50 VDC
Overvoltage Protection		60 VDC
Overload Protection		1.4 A
Short-circuit Protection		Yes
Power-on Value		Yes, Programmable
Safe Value		Yes, Programmable

2-Way Isolation

Ethernet	1500 VDC
I/O	2500 VDC

EMS Protection

ESD (IEC 61000-4-2)	4 kV Contact for each terminal and 8 kV Air for random point
EFT (IEC 61000-4-4)	±4 kV for Power
Surge (IEC 61000-4-5)	±4 kV for Power

LED Indicators
