ICPDAS M-7050
Levertijd:
2~7 dagen
SKU
M-7050
7-channel Sink Type Non-Isolated Digital Input and 8-channel Sink Type Non-Isolated Digital Output Module with 16-bit Counters (Gray Cover)
● Digital input channels: 7
ON Voltage Level: +1 V max.
OFF Voltage Level: +3.5 ~ +30 V
● Digital output channels: 8
● Open collector to 30 V, 30 mA max. load
● Power dissipation: 300 mW
The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
Meer informatie
Art.nr.
M-7050
Fabrikant
ICPDAS
Digital Input
| Channels | 7 | ||||
| Input Type | Source, non-isolated channel with common ground | ||||
| On Voltage Level | +4 V ~ +30 V | ||||
| Off Voltage Level | +1 V max. | ||||
| Input Impedance | 3K9, 0.3 W | ||||
| Counters |
|
Digital Output
| Channels | 8, Sink, NPN |
| Output Voltage | 30 V max. |
| Output Current | 30 mA max. |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
LED Indicators
| 1 LED as Power/Communication indicator |
Protocol
| Support Modbus and DCON Protocol | Yes |
Power
| Input Voltage Range | 10 ~ 30 VDC |
| Power Consumption | 0.4 W |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 5 ~ 95%, non-condensing |
