ICPDAS I-7055-NPN

Levertijd:
2~7 dagen
SKU
I-7055-NPN

8-channel Isolated Digital Input and 8-channel Sink Type Isolated Digital Output Module

● Digital Outputs for Sink Type
● Support Digital Inputs (Sink Type or Source Type)
● Photo Couple Isolation
● Can be Used as Counters
● 4 kV ESD and EFT Protection
● 3 kV Surge Protection for Power Input
● Dual Watchdog
● Power On Value Setting
● Safe Value Setting
● Short Circuit Protection

I-7000 is a family of network data acquisition and control modules. They provide analog-to-digital, digital-to-analog, digital input/output, timer/counter and other functions. These modules can be remote controlled by a set of commands.

ICPDAS Digital Input and Output Module I-7055-NPN offers 8 channels for digital output and 8 channels for digital input. I-7055-NPN 8 channels for digital output each of which features Photo-couple isolation. supports sink type output with short-circuits protection.

There are options for power on value and safe value for your consideration. Moreover, you can choose sink type or source type input by wire connections. All channels are able to be used as 16-bit counters.

APPLICATIONS
● All kinds of On/Off Control
● Industry Automation
● Industrial Machinery
● Building Automation
● Food & Beverage
● Semiconductor Fabrication
● Control System

Meer informatie
Art.nr.
I-7055-NPN
Fabrikant
ICPDAS
Digital Input
Channels 8
Input Type Dry Contact: Source, Wet Contact: Sink or Source
Dry Contact Level
On Voltage Level : Close to GND
Off Voltage Level : Open
Wet Contact Level
On Voltage Level : +10 V ~ +50 V
Off Voltage Level : +4 V max.
Input Impedance 10 kΩ, 0.5 W
Counters
Channels: 8
Max. Counts: 16-bit (65535)
Max. Input Frequency: 100 Hz
Min. Pulse Width: 5 ms
Photo-Isolation 3750 VDC
Digital Output
Channels 8, Sink (NPN)
Output Voltage +5 ~ +50 V
Output Current 700 mA per channel, Direct drive power relay module
Intra-module Isolation, Field to Logic 3750 VDC
Overvoltage Protection 60 VDC
Overload Protection Yes
Short-circuit and Overcurrent Protection 1.4 A
Thermal Overload Trip Temperature 150 °C
Interface
Interface RS-485
Format N, 8, 1
Baud Rate 1200 ~ 115200 bps
LED Indicators
1 LED as Power/Communication indicator
EMS Protection
ESD (IEC 61000-4-2)
±4 kV Contact for each terminal
±8 kV Air for random point
EFT (IEC 61000-4-4)
±4 kV for 8DO and Power
±2 kV for RS-485 port
Surge (IEC 61000-4-5) ±3 kV for power liner
Power
Input Voltage Range 10 ~ 30 VDC
Power Consumption 1.2 W
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +85 °C
Humidity 5 ~ 95% RH, non-condensing
