ICPDAS tM-P3POR3

Levertijd:
2~7 dagen
SKU
tM-P3POR3

3-channel Isolated Digital Input and 3-channel PhotoMOS Relay Output Module

● PhotoMOS Relay Outputs
● Source- or Sink-Type Digital Inputs
● Photocouple Isolation
● All DI channels can be used as 16-bit counters
● Dual Watchdog
● Configurable Power-on Value Settings
● Configurable Safe Value Settings
● Wide Operating Temperature Range: -25 °C ~ +75 °C

The tM-P3POR3 provides 3 digital input channels and 3 PhotoMOS relay output channels, each of which features photocouple isolation. All output channels are PhotoMOS relays, while input is based on a sink- or source-type using a wire connection. All input channels can be used as 16-bit counters.There are options for configuring power-on and safe digital output values. PhotoMOS relays provide a faster response time, greater electrical endurance and no spike. 4 kV ESD protection and 3750 VDC intra-module isolation are also provided.



APPLICATIONS:

● All kinds of On/Off Control
● Industry Automation
● Industrial Machinery
● Building Automation
● Food & Beverage Systems
● Semiconductor Fabrication
● Control Systems

Meer informatie
Art.nr.
tM-P3POR3
Fabrikant
ICPDAS
Digital Input/Counter
Input Channels 3
Type Wet Contact (Sink, Source)
On Voltage Level +3.5 VDC ~ 50 VDC
Off Voltage Level +1.0 Vdc Max.
Input Impedance 10 kΩ, 0.66 W
Counters
Channels 3
Max. Count 65535 (16-bit)
Max. Input Frequency 100 Hz
Min. Pulse Width 5 ms
Overvoltage Protection 70 VDC
Relay Output
Output Channels 3
Relay Type PhotoMOS Relay
Operating Voltage Range 80 V (AC peak or DC)
Max. Load Current 3 A, (1 ms, 1 shot)
Operating Time 5 ms (Max.)
Release Time 0.5 ms (Max.)
Electrical Endurance
Long Life and No Spike
Power-on Value Yes, Programmable
Safe Value Yes, Programmable
Communication Interface
Interface RS-485
Format (N, 8, 1), (N, 8, 2), (O, 8, 1), (E, 8, 1)
Baud Rate 1200 ~ 115200 bps
Protocol DCON, Modbus/RTU, Modbus/ASCII
Dual Watchdog Yes, Module (2.3 seconds), Communication (Programmable)
LED Indicators
1 LED Power Indicator
Isolation
Intra-module Isolation,Field-to-Logic 3750 VDC for Digital Input
2000 VDC for PhotoMOS Relay Output
EMS Protection
ESD (IEC 61000-4-2)
±4 kV Contact for Each Terminal
±8 kV Air for Random Point
EFT (IEC 61000-4-4) ±4 kV for Power
Power
Reverse Polarity Protection Yes
Powered from Terminal Block Yes, 10 ~ 30 VDC
Consumption 0.4 W Max.
Mechanical
Dimensions (w x l x h) 52 x 98 x 27 mm
Installation DIN-Rail Mounting
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -30 °C ~ +75 °C
Humidity 10 ~ 95% RH, Non-condensing
