M-7080 ICPDAS - 2 Channel Counter / Frequency Input Module

Levertijd:
2~7 dagen
SKU
M-7080

Counter/Frequency input module (Gray Cover)

● Counter input: 2 independent 32-bit counter
● Frequency input: 100 KHz max.
● Input: 3750 V isolated or non-isolated
● Non-isolated programmable threshold value
● Programmable digital noise filter

The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.

Meer informatie
Art.nr.
M-7080
Fabrikant
ICPDAS
Counter Input
Channels 2 independent 32-bit counters, counter 0&1
Input Type Isolated or non-isolated
Input Level for Isolation and Non-isolation
Logic level 0: +1 V max.
Logic level 1: +3.5 ~ 30 V
Isolation Voltage 3750 Vrms
Non-Isolated Input Level
(Programmable)
Logic level 0: 0 ~ +5 V (default= 0.8 V)
Logic level 1: 0 ~ +5 V (default= 2.4 V)
Maximum Count
32-bit (4,294,967,295)
Programmable Digital Noise Filter 2 us ~ 65 ms
Alarming Alarm on counter 0 or counter 0 & 1, Programmable
Counter Preset Value Programmable
Frequency Measurement
Input Frequency 1 Hz ~ 100 KHz max.
Gate Time 1.0 or 0.1 sec, programmable
Digital Output
Channels 2
Output Type Sink, Open-Collector
Output Voltage 30 V max.
Output Current 30 mA max
Interface
Interface RS-485
Format N, 8, 1
Baud Rate 1200 ~ 115200 bps
LED Indicators
1 LED Power/Communication indicator
Protocol
Support Modbus and DCON Protocol Yes
Power
Input Voltage Range 10 ~ 30 VDC
Power Consumption 2.0 W (max.)
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +85 °C
Humidity 5 ~ 95%, non-condensing
