CANBus Remote I/O

CANopen Slave Module of 16-channel Isolated Sink/Source Digital Input

● NMT Slave
● Providing I/O Pair-connection Function
● Provide default EDS file
● Passed the validation of CiA CANopen Conformance Test tool
● Support Polarity Output Setting and Save
● Support Error Value Output Setting and Save
● Support Dynamic PDO
● Support Application: PNP, NPN, TTL, and Relay Contact
● ESD Protection 4 kV Contact for each channel

CANopen Slave Module of 16-Channel Isolated Open-collector Digital Output

● NMT Slave
● Providing I/O Pair-connection Function
● Provide default EDS file
● Passed the validation of CiA CANopen Conformance Test tool
● Support Polarity Output Setting and Save
● Support Error Value Output Setting and Save
● Support Dynamic PDO
● Support Application: Drive Relay, Resistance Load
● ESD Protection 4 kV Contact for each channel

CANopen Slave Module of 8-Channel Isolated Digital Input and 8-Channel Isolated Digital Output

● NMT Slave
● Providing Pair-Connect function
● Provide default EDS file
● ESD Protection 4 kV Contact for each channel
● Support Power Supply +10 ~ +30 VDC
● Support CiA DS-301 v4.02, DSP-401 v2.0
● Support PDO Mapping

CAN bus Remote I/O module with CANopen Protocol of 8-Channel PWM and 8-Channel High Speed Counter

● NMT Slave
● Providing Pair-Connect function
● Provide default EDS file
● ESD Protection 4 kV Contact for each channel
● Support Power Supply +10 ~ +30 VDC
● Support CiA DS-301 v4.02, DSP-401 v2.0
● Support PDO Mapping

CAN bus Remote I/O module with CANopen Protocol of 8-Channel PWM and 8-Channel High Speed Counter

● Hardware-controlled PWM output
● PWM output frequency: 0.2 Hz ~ 500 kHz with 0.1%~99.9% duty cycle
● PWM Output Modes: software trigger / hardware trigger
● Trigger each PWM output individually or all PWM outputs synchronously
● Support Burst output mode and Continue output mode
● Provide 32-bit 500 kHz high-speed counter for each DI channel
● Pass the validation of DeviceNet conformance test
● Provide EDS file for DeviceNet master interface

DeviceNet Module of 16-channel Isolated Sink/Source Digital Input

● DeviceNet general I/O slave devices
● Group 2 Only Server (non UCMM-capable)
● Support Predefined Master/Slave Connection Set
● Connection supported (1 connection for Explicit Messaging, 1 connection for Polled I/O, 1 connection for Bit-Strobe I/O connection)
● Provide EDS file for DeviceNet master interface
● Support Application: PNP, NPN, TTL, and Relay Contact
● ESD Protection 4 kV Contact for each channel

DeviceNet Module of 16-channel Isolated Open Collector Digital Output

● DeviceNet general I/O slave devices
● Group 2 Only Server (non UCMM-capable)
● Support Predefined Master/Slave Connection Set
● Connection supported (1 connection for Explicit Messaging, 1 connection for Polled I/O, 1 connection for Bit-Strobe I/O connection)
● Support DeviceNet heartbeat and shutdown messages
● Provide EDS file for DeviceNet master interface
● Support Application: Drive Relay, Resistance Load
● ESD Protection 4 kV Contact for each channel

8-channel isolated sink/source digital input and 8-channel isolated open-collector digital output module

● DeviceNet general I/O slave devices
● Comply with DeviceNet specification Volume I, Release 2.0 & Volume II, Release 2.0, Errata 5
● Group 2 Only Server (non UCMM-capable)
● Support Predefined Master/Slave Connection Set
● Connection supported (1 connection for Explicit Messaging, 1 connection for Polled I/O, 1 connection for Bit-Strobe I/O connection)
● Support DeviceNet heartbeat and shutdown messages
● Provide EDS file for DeviceNet master interface

8-channel 14-bit analog output module

CANopen module of 4-channel 14-bit analog output module

● NMT Slave
● Read-Back Accuracy ±1% of FSR
● Provide default EDS file
● ESD Protection 4 kV Contact for each channel
● Support Power Supply +10 VDC ~ +30 VDC
● Support CiA DS-301 v4.02, DSP-401 v2.1
● Support PDO Mapping

8-channel 14-bit analog input module

● NMT Slave
● NMT Error Control support Guarding and Heartbeat
● Provide default EDS file
● Passed the validation of CiA CANopen Conformance
● Test tool
● Sampling mode support normal and fast mode
● ESD Protection 4 KV Contact for each channel
● Support Power Supply +10 ~ +30 VDC
● Support CiA DS-301 v4.02, DSP-401 v2.1
● Support Dynamic PDO

DeviceNet Slave Module of 8-channel thermocouple input

● DeviceNet general I/O slave devices
● Comply with DeviceNet specification Volume I,
● Release 2.0 & Volume II, Release 2.0, Errata 5
● Group 2 Only Server (non UCMM-capable)
● Support Predefined Master/Slave Connection Set
● Connection supported:
● 1 connection for Explicit Messaging
● 1 connection for Polled I/O
● 1 connection for Bit-Strobe I/O connection
● Support DeviceNet heartbeat and shutdown messages
● Provide EDS file for DeviceNet master interface

CANopen Slave Module of 8-channel RTD Inputs

● Default EDS file
● Passed the validation of CiA CANopen Conformance
● Test tool
● ESD Protection 4 KV Contact for each channel
● Support Power Supply +10 ~ +30 VDC
● Support CiA-301 v4.02, CiA-401 v2.1
● Support Dynamic PDO

6-ch Analog Input, 2-ch Analog Output, 2-ch Digital Input and 1-ch Digital Output CANopen Slave Module

● I/O Channels: 6AI, 2AO, 2DI and 1DO
● Analog Input Type: +/-150mV, +/-500 mV, +/-1V, +/-5 V, +/-10 V +/-20 mA, 0 ~ 20 mA, 4 ~ 20 mA (Current measurement with external 125Ω resistor required )
● Analog Output Type: +0 V ~ +5 V, +/-5 V, +0 V ~ +10 V, +/-10 V
● Analog Input sample rate: 60 Samples/Sec. (Total)
● Digital Input Type: Sink
● Digital Output Type: Sink
● Analog Input Resolution: 16-bit
● Analog Input Accuracy: +/-0.1% FSR
● Analog Output Resolution: 12-bit
● Analog Output Accuracy: +/-0.1% FSR
● ESD Protection: +/- 4kV, Contact for each terminal
● Intra-module Isolation: Field to logic 3000 VDC



4-ch Digital Input and 4-ch Relay Output CANopen Slave Module

● I/O Channels: 4DI and 4DO
● Digital Input Type: Sink/Source
● Digital Output Type: Relay
● Relay Type: Form A (SPST-NO)
● Load: 5A, each channel
● ESD Protection: +/- 4kV, Contact for each terminal
● Intra-module Isolation: Field to logic 3750 VDC

Industrial 4-port CAN bus Switch with Metal casing

● 4 CAN communication ports
● Compatible with CAN specification 2.0A and 2.0B
● Fully compatible with the ISO 11898-2 standard
● Baud rate : 5 k, 10 k, 20 k, 33.3 k, 50 k, 62.5 k, 83.3 k, 125 k, 250 k, 500 k, 800 k, 1 M bps and user-defined
● CAN bus filter is configurable
● 100 data frames buffer for each CAN channel
● Max data flow up to 2500 fps for all CAN channel
● Selectable baud rate by rotary switch
● Selectable 120Ω terminator resistor by DIP switch
● LED for CAN reception and transmission
● Support CAN network with star or tree topology
● Extending the CAN bus distance to expand the CAN network size
● Integrating different CAN network with different baud rate

Modbus RTU to CAN converter

● RoHS Design
● Fully compatible with ISO 11898-2 standard
● Programmable CAN bus baud rate from 10 kbps to 1 Mbps or user-defined baud rate
● Support CAN bus acceptance filter configuration
● Support firmware update via RS-232
● Provide utility tool for module setting and CAN bus communication testing
● Built-in jumper to select 120Ω terminator resistor
● CAN buffer: 128 data frames ; UART buffer: 256 bytes
● Power, data flow and error indicator for CAN and UART status
● Hardware Watchdog design
● Convert CAN message to specific ASCII command string (Normal mode)
● Convert specific ASCII command string to CAN message (Normal mode)
● Provide the transparent communication between the RS-232/485/422 devices via CAN bus (Pair-connection mode)
● Support function code 0x03/0x04/0x10 of Modbus RTU command for reading and writing CAN message (Modbus RTU mode)

4-port CAN bus Switch

● 4 CAN communication ports
● Compatible with CAN specification 2.0A and 2.0B
● Fully compatible with the ISO 11898-2 standard
● Baud rate : 5 k, 10 k, 20 k, 33.3 k, 50 k, 62.5 k, 83.3 k, 125 k, 250 k, 500 k, 800 k, 1 M bps and user-defined
● CAN bus filter is configurable
● 100 data frames buffer for each CAN channel
● Max data flow up to 2500 fps for all CAN channel
● Selectable baud rate by rotary switch
● Selectable 120Ω terminator resistor by DIP switch
● LED for CAN reception and transmission
● Support CAN network with star or tree topology
● Extending the CAN bus distance to expand the CAN network size
● Integrating different CAN network with different baud rate

CAN to WI-Fi Converter

● IEEE 802.11a/b/g compliant
● Wireless data transmission via WLAN
● Two different operation modes: infrastructure and ad-hoc
● Point to point or point to multi-points connection via wireless LAN
● Supports WEP, WPA and WPA2 encryption for wireless LAN
● CAN 2.0A/2.0B compliant
● Connect CAN networks via a WLAN bridge
● Communication efficiency: one-way is up to 700 fps (client->server->client), two-way 350 fps (client<=>server)
● Wireless communication: 100m (Without PA) / 300m (With PA)
