PET-7066 - PoE Ethernet I/O Module with 8-ch PhotoMOS Relay

2~7 dagen

PoE Ethernet I/O Module with 8-ch PhotoMOS Relay

● PoE Ethernet Options
● Built-In Web Server
● Web HMI
● Modbus/TCP, Modbus/UDP Protocol
● Communication Security
● Dual Watchdog
● Operating Temperature: -25 °C ~ +75 °C
● I/O Pair Connection
● Built-In I/O (PhotoMOS Relay: 8 Channels)

The PET-7066 is an Ethernet I/O module with 8 PhotoMOS Relay channels. It features a built-in web server, which allows configuration, I/O monitoring and I/O control by simply using a regular web browser. The PET-7066 module can be remotely controlled by using the Modbus TCP/UDP protocol via the Ethernet network. This makes the modules to be well integrated with HMI, SCADA, PLC, and other industrial control software systems.

The PET-7066 supports IEEE 802.3af Power-Over-Ethernet (Class 1) specifications. By connecting to network devices that support the IEEE 802.3af PoE standard, power can be supplied via the network cable.


Building Automation, Factory Automation, Machine Automation, Remote Maintenance, Remote Diagnosis, and Testing Equipment.

Meer informatie
Built-In Web Server Yes
Web HMI Yes
I/O Pair Connection Yes
Ethernet Port 10/100 Base-TX with Auto MDI/MDI-X
Protocol Modbus/TCP, Modbus/UDP
Security ID, Password and IP Filter
Dual Watchdog Yes, Module (0.8 second), Communication (Programmable)
PhotoMOS Relay
Input Channels 6
Type PhotoMOS Relay, Form A
Load Voltage 60 VDC/VAC
Load Current
(Operating Temperature -25 °C ~ +40 °C)
(Operating Temperature +40 °C ~ +60 °C)
(Operating Temperature +60 °C ~ +75 °C)
Operate Time 1.3 ms (Typical)
Release Time 0.1 ms (Typical)
Power On Value Yes, Programmable
Safe Value Yes, Programmable
2-Way Isolation
Ethernet -
I/O 3000 Vrms
EMS Protection
ESD (IEC 61000-4-2) 4 kV Contact for each terminal
EFT (IEC 61000-4-4) ±2 kV for Power
LED Indicators
LED 1 System Running
LED 2 Ethernet Link/Act
LED 3 Ethernet 10/100 M Speed
LED 4 PoE Power
Reverse Polarity Protection Yes
Powered from Terminal Block Yes, 12 ~ 48 VDC
Powered from PoE Yes, IEEE 802.3af, Class1
Consumption 5.3 W
Dimensions (w x l x d) 72 x 123 x 35mm
Installation DIN-Rail or Wall Mounting
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -30 °C ~ +80 °C
Humidity 10 ~ 90% RH, non-condensing
