ET-7066 - Ethernet I/O Module with 8-ch PhotoMOS Relay

Levertijd:
2~7 dagen
SKU
ET-7066

8-channel PhotoMOS Relay Output Module

● Built-In Web Server
● Web HMI
● Modbus/TCP, Modbus/UDP Protocol
● Communication Security
● Dual Watchdog
● Operating Temperature: -25 °C ~ +75 °C
● I/O Pair Connection
● Built-In I/O (PhotoMOS Relay: 8 Channels)

Introduction
The ET-7066 provides 8 form A PhotoMOS relays. It features optical isolation for 3000 Vrms of transient overvoltage protection and doesn't have channel-to-channel isolation. The power-on value and safe value of the PhotoMOS relay are programmable. It can safely be used in applications where hazardous voltages are present.

Applications
Building Automation, Factory Automation, Machine Automation, Remote Maintenance, Remote Diagnosis, and Testing Equipment.

Meer informatie
Art.nr.
ET-7066
Fabrikant
ICPDAS
Software
Built-In Web Server Yes
Web HMI Yes
I/O Pair Connection Yes
Communication
Ethernet Port 10/100 Base-TX with Auto MDI/MDI-X
Protocol Modbus/TCP, Modbus/UDP
Security ID, Password and IP Filter
Dual Watchdog Yes, Module (0.8 second), Communication (Programmable)
PhotoMOS Relay
Input Channels 6
Type PhotoMOS Relay, Form A
Load Voltage 60 VDC/VAC
Load Current
60V/1.0A
(Operating Temperature -25 °C ~ +40 °C)
60V/0.8A
(Operating Temperature +40 °C ~ +60 °C)
60V/0.7A
(Operating Temperature +60 °C ~ +75 °C)
Operate Time 1.3 ms (Typical)
Release Time 0.1 ms (Typical)
Power On Value Yes, Programmable
Safe Value Yes, Programmable
2-Way Isolation
Ethernet 1500 VDC
I/O 3000 Vrms
EMS Protection
ESD (IEC 61000-4-2) 4 kV Contact for each terminal
EFT (IEC 61000-4-4) ±2 kV for Power
LED Indicators
LED 1 System Running
LED 2 Ethernet Link/Act
LED 3 Ethernet 10/100 M Speed
Power
Reverse Polarity Protection Yes
Powered from Terminal Block Yes, 10 ~ 30 VDC
Powered from PoE -
Consumption 2.9 W
Mechanical
Dimensions (w x l x d) 72 x 123 x 35mm
Installation DIN-Rail or Wall Mounting
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -30 °C ~ +80 °C
Humidity 10 ~ 90% RH, non-condensing
