Axiomtek Panel PC GOT3217WL-845-PCT

Levertijd:
3~4 weken
SKU
GOT3217WL-845-PCT

21.5" FHD TFT Multi-touch Panel Computer with Intel® Pentium® Processor N3710 (0°C to +45°C)

● 21.5" FHD 10-point multi-touch projected capacitive wide screen
● Fanless design with Intel® Pentium® processor N3710
● 2.5" SATA HDD & mSATA
● 4G, WLAN module & antennas (optional)
● 2 Gigabit LANs, 2 USB 3.0, 2 USB 2.0 & 2 COM ports
● IP65 aluminum front bezel
● Supports panel mount and optional VESA arm/desktop stand/ wall mount
● Adjust RS-232/422/485 setting via BIOS



Brochure EN

The GOT3217WL-845-PCT adopts an 21.5-inch FHD LCD and supports Intel® Braswell processor.
The Lite rugged industrial panel PC supports low power Intel® Pentium® processor N3710.
It also provides two PCI Express Mini card slots for 4G, wireless network connectivity.
This 21.5" multi-touch panel computer is suitable for transportation, heavy-duty industry, smart factory automation, and oil pipe monitoring systems.

21.5-inch FHD LCD with Projected Capacitive Multi-touch
The 21.5" FHD touch panel PC supports 250 nits brightness, able to display contents in HD resolution.
With projected capacitive 10-point multi-touch screen, users can operate the device more directly and friendly.
The hardness of touch glass surface is up to 7h for anti-scratch purpose.

WLAN Antenna Supported (optional)
The IP65-rated industrial panel PC, GOT3217WL-845-PCT, provides two PCI Express Mini card slots and WLAN antennas for 4G and wireless network connectivity.

Meer informatie
Art.nr.
GOT3217WL-845-PCT
Fabrikant
Axiomtek
Land van herkomst
Taiwan
Front Bezel
IP65 front bezel
LCD Panel
Display Type 21.5" FHD TFT LCD
Brightness (cd/m2 ) 250 nits
Resolution 1920 x 1080
Main System
CPU Intel® Pentium® processor N3710 4C @1.6 GHz (Braswell)
Onboard Graphics Soc Intergrated
System Memory 1 x 204-pin DDR3L SO-DIMM max.up to 8 GB
Storage  1 x 2.5" SATA HDD
1 x mSATA
BIOS
AMI UEFI BIOS
Watchdog Timer
255 levels, 0~255 sec.
I/O Connector
COM 1 x RS-232
1 x RS-232/422/485 (COM1)
USB 2 x USB 3.0
2 x USB 2.0
Ethernet 2 x 10/100/1000Mbps
Audio Line out & MIC-in
ATX Switch for power on/off
Expansion Interface
1 x Full-Size Mini PCI Express Mini Card with mSATA supported <br>
1 x Full-Size Mini PCI Express Mini Card with SIM Slot
Camera
N/A
Touchscreen
10- point Projected capacitive multi-touch
Power Supply
DC version : 9~36VDC
AC version : 12VDC w/adapter
Grootte
547.6mm (W) x 58.5mm (D) x 339.0mm (H)
Weight (net/gross)
7.6KG / 10.5KG
Environmental
Operating temperature: -10°C ~ +45°C
Relative humidity: 20% ~ 90% @ 40°C; non-condensing
Operation vibration: 1G, 10 ~ 500Hz, random for 2.5" SATA HDD
Certification
CE
Operating System
Windows 7 Professional
Windows 10 Professional
Windows Embedded 7 Standard
