ICPDAS X509
Levertijd:
2~7 dagen
SKU
X509
2-Port RS-232 (3-Pin) add 4-channel D/I, 4-channel D/O board for I-7188XB, I-7188XG, I-7188EX, I-7188EG, μPAC-7186EG
Expansion boards for RS-232/422/485, DI, DO
Meer informatie
Art.nr.
X509
Fabrikant
ICPDAS
Digital Input
| Channels | 4 | ||
| Input Voltage |
|
||
| Isolated | None |
Digital Output
| Channels | 4 |
| Open-collector Output | 100 mA / 30V max. |
| Isolated | None |
Parallel I/O Module
| RS-232 Ports | 2 |
| COM3 | TXD, RXD, GND |
| COM4 | TXD, RXD, GND |
| 16550 compatible | |
| Internal FIFO | 16 bytes |
| Transmission Speed | 115.2K BPS max. |
| Isolated | None |
