ICPDAS X510-128
Levertijd:
2~7 dagen
SKU
X510-128
1-Port RS-232 (3-Pin) add 5-channel D/I, 5-channel D/O, EEPROM 128K x1 board for I-7188XB, I-7188XG, I-7188EX, I-7188EG, μPAC-7186EG
(EG/XG not supporting EEPROM and Flash memory)
Expansion boards for RS-232/422/485, DI, DO
Meer informatie
Art.nr.
X510-128
Fabrikant
ICPDAS
Digital Input
| Channels | 5 | ||
| Input Voltage |
|
||
| Isolated | None |
Digital Output
| Channels | 5 |
| Open-collector Output | 100 mA / 30V max. |
| Isolated | None |
Parallel I/O Module
| RS-232 Ports | 1 |
| COM3 | TXD, RXD, GND |
| 16550 compatible | |
| Internal FIFO | 16 bytes |
| Transmission Speed | 115.2K BPS max. |
| EEPROM | 128K * 1 bytes |
| Endurance | 100.000 Write Cycles/Page |
| Data Retention | 40 Years |
| Isolated | None |
Specifications
| Power Consumption | 0.7 W |
