ICPDAS X300
Levertijd:
2~7 dagen
SKU
X300
2-channel D/A (0 ~ 4.095V)board for I-7188XC
D/A boards on 40MHZ CPU the throughput rate is 900 samples/second max.
Meer informatie
Art.nr.
X300
Fabrikant
ICPDAS
Analog Output
| Output Channels | 2 |
| Output Type | 0 ~ 4.095V |
| Resolution | 12-bit |
| Output Capacity | 5mA |
| Isolation Voltage | Non-isolation |
Specifications
| Power Requirement | +5VDC |
| Dimensions | 64 x 32mm |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +80 °C |
| Humidity | 5% to 90% Non-condensing |
