ICPDAS X302
Levertijd:
2~7 dagen
SKU
X302
1-channel A/D (±5 V), 1-channel D/A (±5 V) board for I-7188XC
A/D boards on 40MHZ CPU the sampling rate is 1.8K samples/second max.
Meer informatie
Art.nr.
X302
Fabrikant
ICPDAS
Analog Input
| Input Channel | 1 |
| Input Type | ±5V |
| Resolution | 12-bit |
| Sampling Rate | 900Hz max. |
| Input Impedance | 50 KΩ |
| Overvoltage Protection | ±5VDC |
| Isolation Voltage | Non-isolation |
Analog Output
| Input Channel | 1 |
| Output Type | ±5V |
| Resolution | 12-bit |
| Output Capacity | 10mA |
| Isolation Voltage | Non-isolation |
Specifications
| Power Requirement | +5VDC |
| Dimensions | 64 x 32mm |
Omgeving
| Operating Temperature | -25°C ~ +75 °C |
| Storage Temperature | -40 °C ~ +80 °C |
| Humidity | 5% to 90% Non-condensing |
