ICPDAS X304
Levertijd:
2~7 dagen
SKU
X304
3-channel A/D (±5 V), 1-channel D/A (±5V) add 4-channel D/I, 4-channel D/O board for I-7188XB/XG/EX/EG, μPAC-7186XB/XG/EX/EG-FM/SM/SD/FD
A/D boards on 40MHZ CPU the sampling rate is 1.8K samples/second max.
D/A boards on 40MHZ CPU the throughput rate is 900 samples/second max.
Meer informatie
Art.nr.
X304
Fabrikant
ICPDAS
Analog Input
| Input Channels | 3 |
| Input Type | ±5V |
| Resolution | 12-bit |
| Sampling Rate | 1 kHz max. (Read one channel) |
| Input Impedance | 50 kΩ |
| Overvoltage Protection | ±30VDC |
| Isolation Voltage | Non-isolation |
Analog Output
| Output Channels | 1 |
| Output Type | ±5V |
| Resolution | 12-bit |
| Output Capacity | 10mA |
| Isolation Voltage | Non-isolation |
Digital Input
| Input Channels | 4 |
| Input Type | Sink, non-isolated channel with common ground |
| On Voltage Level | +3.5V ~ +30VDC |
| Off Voltage Level | +1V max. |
| Isolation Voltage | Non-isolation |
Digital Output
| Output Channels | 4 |
| Output Type | Open-Collector (NPN) |
| Load Voltage | +30VDC, max. |
| Load Current | 100mA, max. |
| Isolation Voltage | Non-isolation |
Specifications
| Power Requirement | +5VDC |
| Dimensions | 64 x 38mm |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +80 °C |
| Humidity | 5% to 90% Non-condensing |
