ICPDAS RU-87P4
Levertijd:
2~7 dagen
SKU
RU-87P4
4 slots I/O expansion unit (Gray Cover)
● One RS-485 Port for Multi-Drop Topology
● I/O Module Hot Swap
● Auto Configuration
● LED Indicators for Fault Detection
● Switches to Configure Communication
● DCON Protocol
● 4 I/O Slots for I-87K Modules
● Operating Temperature: -25 °C ~ +75 °C
RU-87Pn series is a remote intelligent I/O expansion unit to expand I-87K series I/O modules over the RS-485 for industrial monitoring and controlling applications.
RU-87Pn is designed to be used in harsh and noisy environment, so the hardware is manufactured with wide power input range (10 ~ 30 VDC), isolated power input and can operate under wide temperature (-25 °C ~ +75 °C).
To simplify installation and maintenance of I/O modules, it provides many useful features, such as: hot swap allowed, auto configuration, LED indicators for fault detection, dual watchdog to keep alive, programmable power on and safe values for safety.
There are more than 30 I/O modules supported with the unit, including analog input/output, digital input/output, counter, frequency I/O modules. We provide various software development kits (SDK) and demos, such as DLL, ActiveX, Labview driver, InduSoft driver, Linux driver, OPC server, etc. The I-87K series I/O modules plugged in the RU-87Pn can be easily integrated into variant software system.
APPLICATIONS:
Meer informatie
Art.nr.
RU-87P4
Fabrikant
ICPDAS
Interface
| Baud Rate | 115200 bps maximum |
| Distance | 1.2 Km (4000 ft) maximum |
| Isolation | 3000 V DC |
| ESD Protection | ±4K Contact Discharge and ±8K Air Discharge |
| Communication Protocol | DCON Protocol (ASCII format) |
Switch
| Rotary Switch | x2 , For RS-485 address |
| DIP Switch | 8 bit *1, For auto configuration, check sum and baud rate |
LED Indicators
| Power | Yes |
| System Ready | Yes |
| Auto Configuration | Yes |
| Slot Status | Yes |
I/O Expansion Slots
| Hot Swap | Yes |
| Auto Configuration | Yes |
| Support Module Type | High profile I-87K module only |
| Slots | 4 |
Mechanical
| Dimensions (w x h x d) | 188 x 132 x 111mm |
Omgeving
| Operating Temperature | -25 ~ +75 °C |
| Storage Temperature | -30 ~ +75 °C |
| Humidity | 5 ~ 95%, Non-condensing |
Power
| Input Range | 10 ~ 30V DC (non-regulated) |
| Reverse Polarity Protection | Yes |
| Isolation | 1000V DC |
| Frame Ground | Yes |
| Power Consumption | 2W |
| Power Board Driving | 32W |
