ICPDAS PCI-1602U

Levertijd:

2~7 dagen

SKU

PCI-1602U

Universal PCI, 32-channel, 16-bit, 100 kS/s Low Gain Multi-function DAQ Board (8 K word FIFO)

● Universal PCI interface, supports both +5 V and +3.3 V PCI bus
● Card ID function
● Pull-high/ pull-low resistors for DI
● 16-channels digital Input
● 16-channels digital output
● 2 channels, 12-bit analog output
● 16-bit high resolution, 100 kS/s A/D converter
● 32 single-ended/16 differential analog inputs
● Programmable low gain:1/2/4/8
● Built-in 8 k WORD FIFO
● Built-in MagicScan controller
● Support internal/external trigger
● Three external triggers: post-trigger, pre-trigger, middle-trigger

SOFTWARE FEATURES:

● DOS Lib and TC/BC/MSC sample program (with source codes)
● DLL and OCX SDK for Windows 95/98/NT/2K
● DLL and OCX SDK for 32-bit and 64-bit Windows XP/2003/Vista/7
● VB/VC/Delphi/BCB/VB.NET/C#.NET sample programs with source codes are included
● LabVIEW toolkit for Windows
● Driver for Linux

Brochure EN

Details

The PCI-1602U/1602FU is a high performance multifunction card providing high-speed analog I/O and digital I/O functions. The PCI-1602U/1602FU has a universal PCI interface supporting both 3.3 V and 5 V PCI bus, and it features a continuous, 100 kS/s (200 kS/s for F version) 16-bit resolution A/D converter, 8 K-sample hardware FIFO, a MagicScan controller (for multi-channel scan), 2-channel 16-bit D/A converter, 16-channel digital input and 16-channel digital output.

The PCI-1602U/1602FU provides either 32-channel single-ended or 16-channel differential analog inputs which are jumper selectable, and a programmable high speed PGA is equipped for gain controls (1, 2, 4 and 8). The PCI-1602U/FU are fully compatible with the PCI-1602/F, and users can replace the PCI-1602/F by the PCI-1602U/FU directly without software/driver modification.

The PCI-1602U/1602FU has a Card ID switch for users to recognize the board by the ID via software when using two or more PCI-1602U/1602FU cards in one computer. The pull-high/pull-low jumpers of the card allow user to predefine the DI status instead of floating when the DI channels are unconnected or broken.

The PCI-1602U/1602FU cards support Linux, DOS, Windows 98/NT/2000 and 32/64-bit Windows XP/2003/2008/Vista/7. The SDK of the I/O cards provides DLL, Active X control, and sample programs with source code for users to implement application programs quickly and easily. The demo programs with source code in Turbo C, Borland C, Microsoft C, Visual C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and LabVIEW are provided.

ICP DAS discontinues the /NDA model (without D/A function) since the standard model provides full functions that covers the requirement for /NDA version. Please contact us for OEM/ODM project if you are interested in customized version (or /NDA model).

APPLICATIONS:

● High speed data acquisition system
● Process monitor and control
● Vibration analysis
● Digital pattern generator from digital I/O port

SPECIFICATIES

Meer informatie

Art.nr.

PCI-1602U

Fabrikant

ICPDAS

Analog Input

Channels	32 single-ended/16 differential
AD Conversion	16-bit, 2 μs conversion time
Sampling Rate	100 kS/s. max.
FIFO Size	8192 samples
Overvoltage Protection	Continuous ±35 Vp-p
Input Impedance	10 MΩ/6 pF
Trigger Modes	Software, Internal programmable pacer, External (5 V/TTL compatible)
Data Transfer	Polling
Accuracy	0.01 % of FSR ±1 LSB @ 25 °C, ±10 V
Zero Drift	±2 ppm/°C of FSR

Analog Output

Channels	2
Resolution	12-bit
Accuracy	0.06% of FSR ±1 LSB @ 25 °C, ±10 V
Output Range	Bipolar: ±5 V, ±10 V
Output Driving	±5 mA
Slew Rate	8.33 V/μs
Output Impedance	0.1 Ω max.
Operating Mode	Software
