ICPDAS tM-SG4
Levertijd:
2~7 dagen
SKU
tM-SG4
RS-485 Pull-high/Pull-low and Termination Resistors Module
● Switch-selectable Pull-high/Pull-low Resistors
● 15-step Switch-selectable Termination Resistor
● LED Indicator for Power/Termination
● DIN-Rail Mountable
● Cost-effective
● Wide Operating Temperature Range: -25 °C ~ +75 °C
The tM-SG4 is an optional module that is used to improve the communication of RS-485 network. It provides switch selectable pull-high and pull-low resistors on RS-485 network. It also has 15-step switch selectable termination resistor such that the user can select a proper termination resistor to be connected to the RS-485 network easily.
Meer informatie
Art.nr.
tM-SG4
Fabrikant
ICPDAS
Interface
| Interface | RS-485 |
| Pull-high/pull-low Resistance | 1 kΩ, 10 kΩ, 100 kΩ, Switch-selectable |
| Termination Resistance | 15 Steps, 65 ~ 560 Ω |
LED Indicators
| 1 Red LED | Power Indicator |
| 1 Green LED | Termination Indicator |
Power
| Reverse Polarity Protection | Yes |
| Powered from Terminal Block | Yes, 10 ~ 30 VDC |
| Consumption | 0.5 W (max.) |
Mechanical
| Dimensions (w x l x h) | 52 x 87 x 27mm |
| Installation | DIN-Rail Mounting |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 10 ~ 90% RH, Non-condensing |
