ICPDAS USB-2064-16

The USB-2064-16 is a full-speed USB device with 16-channel power relay output module, and offers features for industrial control and manufacturing test applications, such as factory automation or embedded machine control. The USB-2064-16 provides a power rated relay with 3A maximum current contact rating for switching. Besides, the USB-2064-16 also features power-on value to customize the initial state. Moreover, the safety value can be used to secure the devices in the field. With the true Plug & Play capability, it needs not opening up your computer chassis to install boards-just plug in the module, then get or set the data. Owing to another USB feature known as "hot-swapping", users do not even need to shut down and restart the system to attach or remove the USB-2064-16.

The USB I/O utility can help users to configure and test USB-2064-16 quickly and easily without programming; In addition, we also provide the friendly API library and demos for users to develop own USB application with various application development tools (VB / C++ / C#.NET / VB.NET). Therefore, the USB-2064-16 is the perfect way to add control capability to any USB capable computer.
