ICPDAS tM-R5

Levertijd:

2~7 dagen

SKU

tM-R5

5-channel Relay Output Module

● Relay Outputs
● Dual Watchdog
● Configurable Power-on Value Settings
● Configurable Safe Value Settings
● Cost-effective
● Operating Temperature Range: -25 °C ~ +75 °C

Brochure EN

Details

The tM-R5 provides 5 channels for relay output. All output channels are Form A type relays and there are options for configuring power-on and safe digital output values. 4 kV ESD protection and 3750 VDC intra-module isolation are also provided.

APPLICATIONS:

● All kinds of On/Off Control
● Industrial Automation
● Industrial Machinery
● Building Automation
● Food & Beverage Systems
● Semiconductor Fabrication
● Control Systems

SPECIFICATIES

Meer informatie

Art.nr.

tM-R5

Fabrikant

ICPDAS

Relay Output

Output Channels

Type

Power Relay, Form A (SPST N.O.)

Operating Voltage

250 VAC or 30 VDC

Max. Load Current

5 A

Operating Time

6 ms

Release Time

3 ms

Electrical Life (Resistive load)

VDE	5 A @250 VAC 30,000 ops (10 ops/minute) at 75 °C
	5 A @30 VDC 70,000 ops (10 ops/minute) at 75 °C
UL	5 A @250 VAC/30 VDC 6,000 ops
	3 A @250 VAC/30 VDC 100,000 ops

Mechanical Life

20,000,000 ops at no load (300 ops/minute)

Power-on Value

Yes, Programmable

Safe Value

Yes, Programmable

Communication Interface

Interface	RS-485
Format	(N, 8, 1), (N, 8, 2), (O, 8, 1), (E, 8, 1)
Baud Rate	1200 ~ 115200 bps
Protocol	DCON, Modbus/RTU, Modbus/ASCII
Dual Watchdog	Yes, Module (2.3 seconds), Communication (Programmable)
