ICPDAS M-7024
Levertijd:
Uit voorraad leverbaar
SKU
M-7024
4-channel 14-bit Analog Output Module (Gray Cover)
● Resolution: 14-bit
● Current output: 0 ~20 mA, 4 ~20 mA
● Voltage output: ±10 V, 0 ~ 10 V, ±5 V, 0 ~ 5 V
● Programmable output slew rate:
0.0625 ~ 1024 V/sec.
0.125 ~ 2048 mA/sec.
The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
Meer informatie
Art.nr.
M-7024
Fabrikant
ICPDAS
Analog Output
| Output Channels | 4 | ||
| Output Type | 0 ~ 20 mA, 4 ~ 20 mA, 0 ~ 5 V, ±5 V, 0 ~10 V, ±10 V | ||
| Resolution | 14-bit | ||
| Accuracy | ±0.1% of FSR | ||
| Read Back Accuracy | ±1% of FSR | ||
| Zero Drift |
|
||
| DA Output Response Time | 10 ms per channel | ||
| Span Temperature Coefficient | ±20 ppm/ °C | ||
| Programmable Output Slope |
|
||
| Current Load Resistance | External +24 V power: 1050 Ω | ||
| Photo-Isolation | 3750 Vrms | ||
| Intra-module Isolation, Field to Logic | 3000 VDC |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
LED Indicators
| 1 LED | Power/Communication indicator |
Protocol
| Support Modbus and DCON Protocol | Yes |
Power
| Input | +10 ~ +30 VDC |
| Power Consumption | 2.4 W |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 5 ~ 95%, non-condensing |
