ICPDAS M-7022 2-channel 12-bit Analog Output Module (channel to channel isolation) (Gray Cover) ● Resolution: 12-bit ● Analog output channel: 2 ● Current output: 0 ~ 20 mA, 4 ~ 20 mA ● Voltage output: 0 ~ 10 V ● Channel to channel isolated ● Programmable output slew rate 0.0625 ~ 512 V/sec. 0.125 ~ 1024 mA/sec.
The M-7000 series is a family of network data acquisition and control modules that support Modbus RTU and DCON protocols. With the Modbus RTU protocol, it can easily communicate with most popular SCADA/HMI software and PLC. It has the same form factor as the I-7000 series.
Meer informatie
Analog Output
Output Channels
2, Channel to channel isolation
Output Type
0 ~ 20 mA , 4 ~ 20 mA and 0 ~ 10 V
Resolution
12-bit
Accuracy
±0.1% of FSR
Read Back Accuracy
±1% of FSR
Zero Drift
Current output : ±0.2 uA/°C
Voltage output : ±10 uV/°C
DA Output Response Time
10 ms per channel
Span Temperature Coefficient
±25 ppm/ °C
Programmable Output Slope
0.125 ~ 1024 mA/ second
0.0625 ~ 512 V/ second
Current Load Resistance
Internal power: 500 Ω
External 24V: 1050 Ω
Photo-Isolation
3750 Vrms
Intra-module Isolation, Field to Logic
3000 VDC
Interface
Interface
RS-485
Format
N, 8, 1
Baud Rate
1200 ~ 115200 bps
LED Indicators
Power/ Communication
Protocol
Support Modbus and DCON Protocol
Yes
Power
Input
+10 ~ +30 VDC
Power Consumption
3.0 W
Omgeving
Operating Temperature
-25 °C ~ +75 °C
Storage Temperature
-40 °C ~ +85 °C
Humidity
5 ~ 95%, non-condensing
