ICPDAS PISO-P32A32-5V

The PISO-P32A32 has 32 channels of optically isolated digital input and 32 channels of optically isolated digital output, arranged into four isolated banks. Each input channel uses a photo-coupler input which allows either internal isolated power supply or external power selected by jumper.

Each digital output offers a PNP transistor and integral suppression diode for the inductive load. Isolated input channels 0-15 are designed into group A and channels 16-31 group B. Isolated output channels are designed into group C and Group D. The power supply of the input port may use the external power or internal power. The power supply of the output port should use the external power.

This interface board is easily installed in any PC. The board interface to field logic signals, eliminating ground-loop problems and isolating the host computer from damaging voltages. The PISO-P32A32 has one 37-pin D-Sub connector and one 40-pin male header. The 40-pin to DB-37 flat-cable is used to fix with thecase. The user can connect the digital signal through the second D-Sub connector. Each D-Sub connector contains 16 input channels and 16 output channels.

The PISO-P32A32 supports various OS such as Linux, DOS, Windows 98, Windows 2000, Windows NT, Windows XP 32-Bit, Vista 32-Bit and Windows 7 32-Bit. It also provides the DLL and Active X control, and various language sample programs in Turbo C++, Borland c++, Microsoft C++, Visual C++, Borland Delphi, Borland C++ Builder, Visual Basic, C#.NET, Visual Basic.NET and LabVIEW to help users to quickly and easily develop their applications.


SOFTWARE:

● DOS Lib and TC/BC/MSC sample program (with source codes)
● DLL and OCX SDK for Windows 95/98/NT/2K
● DLL and OCX SDK for 32-bit Windows XP/2003/Vista and 32-bit Windows 7
● VB/VC/Delphi/BCB/VB.NET/C#.NET sample programs with source codes are included
● LabVIEW toolkit for Windows
● Driver for Linux


APPLICATIONS:

● Factory Automation
● Product Test
● Laboratory Automation
