ICPDAS PET-7053
Levertijd:
2~7 dagen
SKU
PET-7053
16-channel Isolated Digital Input Module with 32-bit Counters PoE Module
● PoE Ethernet Options
● Built-In Web Server
● Web HMI
● Modbus/TCP, Modbus/UDP Protocol
● Communication Security
● Dual Watchdog
● Operating Temperature: -25 °C ~ +75 °C
● I/O Pair Connection
● Built-In I/O (DI/Counter: 16 Channels)
The ET-7000/PET-7000, a web-based Ethernet I/O module, features a built-in web server which allows configuration, I/O monitoring and I/O control by simply using a regular web browser. Remote control is as easy as surfing the Internet.
Besides, with the web HMI function, no more programming or HTML skills are required; creating dynamic and attractive web pages for I/O monitoring and I/O control would be fun to engineers ever after. The ET-7000/PET-7000 offers easy and safe access for users from anytime and anywhere! In addition, the ET-7000/PET-7000 also supports Modbus/TCP protocol that makes perfect integration to SCADA software.
Furthermore, PET-7000 features "PoE" that not only data but also power is carried through an Ethernet cable. This feature makes installation of PET-7000 a piece of cake. Imagine that no more unnecessary wires, only an Ethernet cable takes care of everything in the field.
The PET-7053, a web-based Ethernet I/O module, features a built-in web server, which allows configuration, I/O monitoring and I/O control by simply using a regular web browser. Besides, with the web HMI function, no more programming or HTML skills are needed; creating dynamic and attractive web pages for I/O monitoring and I/O control would be fun to engineers ever after. The PET-7053 offers easily and safely access for users from anytime and anywhere! In addition, the PET-7053 also supports Modbus/TCP protocol that makes perfect integration for PET-7053 to SCADA software.
The PET-7053 provides 16 isolated dry contact (source type) digital input channels. Each digital input channel supports counter input (32 bits and 500Hz max.).
APPLICATIONS:
● Building Automation
● Factory Automation
● Machine Automation
● Remote Maintenance
● Remote Diagnosis
● Testing Equipment
Meer informatie
Art.nr.
PET-7053
Fabrikant
ICPDAS
Software
| Built-In Web Server | Yes |
| Web HMI | Yes |
| I/O Pair Connection | Yes |
Communication
| Ethernet Port | 10/100 Base-TX with Auto MDI/MDI-X |
| Protocol | Modbus/TCP, Modbus/UDP |
| Security | ID, Password and IP Filter |
| Dual Watchdog | Yes, Module (0.8 second), Communication (Programmable) |
Digital Input/Counter
| Input Channels | 16 | ||||||
| Type | Dry Contact (Source) | ||||||
| On Voltage Level | Open | ||||||
| Off Voltage Level | Close to GND | ||||||
| Counters |
|
||||||
| Overvoltage Protection | - | ||||||
| Effective Distance | 500 M max. |
2-Way Isolation
| Ethernet | - |
| I/O | 3750 Vrms |
EMS Protection
|
LED Indicators
| LED 1 | |System Running |
| LED 2 | Ethernet Link/Act |
| LED 3 | Ethernet 10/100 M Speed |
| LED 4 | PoE Power |
Power
| Reverse Polarity Protection | Yes |
| Powered from Terminal Block | Yes, 12 ~ 48 VDC |
| Powered from PoE | Yes, IEEE 802.3af, Class1 |
| Consumption | 4.3 W |
Mechanical
| Dimensions (w x l x d) | 72 x 123 x 35mm |
| Installation | DIN-Rail or Wall Mounting |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
