ICPDAS PET-7260
Levertijd:
2~7 dagen
SKU
PET-7260
PoE Ethernet I/O Module with 2-port Ethernet Switch and 6 Digital In / Counter and 6 Power Relay
● Built-in Web Server
● Web HMI
● Support for both Modbus TCP and Modbus UDP Protocols
● Communication Security
● Dual Watchdog
● Wide Operating Temperature Range: -25 ~ +75°C
● I/O Pair Connection
● Built-in I/O
● DI/Counter: 6 Channels
● Power Relay: 6 Channels
The PET-7260, PoE Ethernet I/O Module with 2 port Ethernet Switch, provides 6 wet contact digital input channels and 6 form A electromechanical relays. It features optical isolation for 3000 VDC of transient overvoltage protection and doesn’t have channel-to-channel isolation. Each input channel can be used as a 32-bit counter. The power-on value and safe value of relay are programmable.
Meer informatie
Art.nr.
PET-7260
Fabrikant
ICPDAS
Software
| Built-In Web Server | Yes |
| Web HMI | Yes |
| I/O Pair Connection | Yes |
Communication
| Ethernet Port | 10/100 Base-TX with Auto MDI/MDI-X |
| Protocol | Modbus/TCP, Modbus/UDP |
| Security | ID, Password and IP Filter |
| Dual Watchdog | Yes, Module (0.8 seconds), Communication (Programmable) |
Digital Input/Counter
| Digital Input/Counter | |||
| Channels | 6 | ||
| Contact | Wet Contact | ||
| Sink/Source (NPN/PNP) | Sink/Source | ||
| On Voltage Level | +10 VDC ~ +50 VDC | ||
| Off Voltage Level | +4 VDC Max. | ||
| Input Impedance | 10 kΩ | ||
| Counters | Max. Count | 4,294,967,285 (32 bits) | |
| Max. Input Frequency | 500 Hz | ||
| Min. Pulse Width | 1 ms | ||
| Overvoltage Protection | +70 VDC | ||
Power Relay
| Power Relay | ||||
| Channels | 6 | |||
| Type | Power Relay, Form A (SPST N.O.) | |||
| Contact Rating | 5 A @ 250 VAC/24 VDC (Resistive Load) | |||
| Min. Contact Load | 10 mA @ 5 V | |||
| Operate Time | 10 ms (max.) | |||
| Release Time | 5 ms (max.) | |||
| Mechanical Endurance | 2 × 107 ops. | |||
| Electrical Endurance | 105 ops. | |||
| Power-on Value | Yes, Programmable | |||
| Safe Value | Yes, Programmable | |||
2-Way Isolation
| Ethernet | 1500 VDC |
| I/O | 2500 VDC |
EMS Protection
| ESD (IEC 61000-4-2) | 4 kV Contact for each terminal and 8 kV Air for random point |
| EFT (IEC 61000-4-4) | ±4 kV for Power |
| Surge (IEC 61000-4-5) | ±4 kV for Power |
LED Indicators
| L1 | System Running |
| L2 | Ethernet Link/Act |
| L3 | Ethernet 10/100 M Speed |
Power
| Reverse Polarity Protection | Yes |
| Powered from Terminal Block | Yes, 12 ~ 48 VDC |
| Powered from PoE | - |
| Consumption | 4.1 W |
Mechanical
| Dimensions (w x l x h) | 72 x 123 x 35mm |
| Installation | DIN-Rail or Wall Mounting |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
