ICPDAS I-87019PW
Levertijd:
2~7 dagen
SKU
I-87019PW
8-channel Thermocouple Input Module with High Overvoltage Protection
● 8-channel Analog Input
● Individual Channel Configuration
● Open Thermocouple Detection
● Temperature Output Consistency
● Stable Temperature Output in the Field
● 240 Vrms Overvoltage Protection
● Jumper Selectable Voltage or Current Input
● 4 kV ESD Protection
● Dual Watchdog
● 3000 VDC Intra-Module Isolation, Field-to-Logic
● Wide Operating Temperature Range: -25 °C ~ +75 °C
With different communication interface, the I/O modules can be classified to high communication speed (Parallel bus) 8K series modules and low communication speed (serial interface) 87K series modules.
| There are two types of I/O modules, Parallel and Serial. The parallel modules (I-8 Series) are high-speed modules and support MCU (Main Control Unit) only. | |
| Item | I-87K Series |
| Communication Interface | Serial Bus |
| Protocol | DCON |
| Communication Speed | Slow |
| DI with Latched Function | Y |
| DI with Counter Input | Y (100 Hz) |
| Power On Value | Y |
| Safe Value | Y |
| Programmable Slew-rate for AO Module | Y |
High Profile VS Low Profile
With different form factor, I/O modules can be classified to high profile and low profile. Basically, high profile and low profile modules that with same item number also have same I/O channel number.
For example: I-8054 and I-8054W both has 8 DI and 8 DO.
Except I/O channel number, other specifications could be different. You have to double check whether the specifications suit your application.
For example: For I-8054W, its DI logic high level is +10 ~ +50V. But for I-8054, it is +3.5 ~ +30V
| I-87K Series | ||
| High Profile | Low Profile | |
| XPAC | Y | - |
| WinPAC | Y | - |
| LinPAC | Y | - |
| iPAC | Y | - |
| ViewPAC | Y | - |
| RU-87P1/2/4/8 | Y | - |
| USB-87P1/2/4/8 | Y | - |
| WinCon | Y | Y |
| LinCon | Y | Y |
| I-8000 | Y | Y |
| I-8KE4/8 | Y | Y |
| I-8KE4/8-MTCP | Y | Y |
| I-87K4/5/8/9 | Y | Y |
The ICPDAS Analog Input Module I-87019PW is a serial interface and 8-channel thermocouple input module. The analog input range is software selectable and supports ±15 mV, ±100 mV, ±150 mV, ±500 mV, ±1 V, ±2.5 V, ±5 V, ±V10, ±20 mA, or 0 ~ 20 mA, and thermocouples of type J, K, T, E, R, S, B, N, C, L, M, and LDIM43710. The I-87019PW uses an external terminal design, and ensures thermocouple temperature output consistency.
APPLICATIONS:
● Building Automation
● Factory Automation
● Machine Automation
● Remote Maintenance
● Remote Diagnosis
● Testing Equipment
Meer informatie
Art.nr.
I-87019PW
Fabrikant
ICPDAS
Analog Input
| Input Channels | 8 Differential | ||||
| Web HMI |
|
||||
| Resolution | 16-bit | ||||
| Sampling Rate | 10 Samples/Second (Total) | ||||
| Accuracy | ±0.1% | ||||
| Zero Drift | ±20 μV/°C | ||||
| Span Drift | ±25 ppm/°C | ||||
| Common Mode Rejection |
86 dB |
||||
| Normal Mode Rejection | 100 dB | ||||
| Input Impedance |
|
||||
| Overvoltage Protection | 240 Vrms | ||||
| Open Thermocouple Detection | Yes, Settings Enabled/Disabled via Software | ||||
| Individual Channel Configuration | Yes | ||||
| ESD Protection | ±4 kV, Contact for Each Terminal | ||||
| Intra-module Isolation, Field-to-Logic | 3000 VDC |
Interface
| Interface | RS-485 |
| Format | N, 8, 1 |
| Baud Rate | 1200 ~ 115200 bps |
Watchdog
| Dual Watchdog |
|
LED Indicators
| 1 LED | Power/Communication Indicator |
Power
| Power Consumption | 1.3 W (max.) |
Mechanical
| Dimensions (w x l x h) | 30 x 86 x 114 mm |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +85 °C |
| Humidity | 10 ~ 90% RH, Non-condensing |
