ICPDAS I-87017ZW

With different communication interface, the I/O modules can be classified to high communication speed (Parallel bus) 8K series modules and low communication speed (serial interface) 87K series modules.

High Profile VS Low Profile

With different form factor, I/O modules can be classified to high profile and low profile. Basically, high profile and low profile modules that with same item number also have same I/O channel number.

For example: I-8054 and I-8054W both has 8 DI and 8 DO.

Except I/O channel number, other specifications could be different. You have to double check whether the specifications suit your application.

For example: For I-8054W, its DI logic high level is +10 ~ +50V. But for I-8054, it is +3.5 ~ +30V

The ICPDAS Analog Input Module I-87017ZW is an analog input module that includes 10 differential analog input channels or 20 single-ended analog input channels and provides a programmable input range on all analog inputs (±150 mV, ±500 mV, ±1 V, ±5 V, ±10 V, ±20 mA or 0 ~ 20 mA). Each analog input can be configured for an individual range and provides a high overvoltage protection of 240 Vrms. Voltage and current inputs are jumper selectable. The I-87017ZW is more suitable for critically harsh environments. The sampling rate of the I-87017ZW is adjustable and is available in either fast or normal mode. The ICPDAS Analog Input Module I-87017ZW also provides 4 kV ESD protection as well as 3000 V DC intra-module isolation.

APPLICATIONS:

● Industrial Automation
● Industrial Machinery
● Building Automation
● Food and Beverage Systems
● Semiconductor Fabrication
● Control Systems
