ICPDAS I-7022 - 2-channel 12-bit analog output module

Levertijd:
2~7 dagen
SKU
I-7022

● Resolution: 12 bit
● Analog output channel: 2
● Current output: 0 ~ 20 mA, 4 ~ 20 mA
● Voltage output: 0 ~10V
● Channel to channel isolated
● Dual Watchdog

I-7000 is a family of network data acquisition and control modules. They provide analog-to-digital, digital-to-analog, digital input/output, timer/counter and other functions. These modules can be remote controlled by a set of commands.

ICPDAS Analog Output Module I-7022 provides cost-effective protection and conditioning for a wide range of valuable industrial control signals and systems.

The DCON utility can help users to configure and test I-7022 analog output modules. Plenty of library functions and demo programs are provided to let users develop programs easily under Windows, Linux and DOS operating systems Users may mount the modules on a DIN-Rail, panel or wall. Modules have a screw-terminal block to connect to the signals.

Meer informatie
Art.nr.
I-7022
Fabrikant
ICPDAS
Analog Output
Output Channels 2, Channel to channel isolation
Output Type 0 ~ 20 mA , 4 ~ 20 mA and 0 ~ 10 V
Resolution 12-bit
Accuracy ±0.1% of FSR
Read Back Accuracy ±1% of FSR
Zero Drift
Current output : ±0.2 uA/°C
Voltage output : ±10 uV/°C
DA Output Response Time 10 ms per channel
Span Temperature Coefficient ±25 ppm/ °C
Programmable Output Slope
0.125 ~ 1024 mA/ second
0.0625 ~ 512 V/ second
Current Load Resistance
Internal power : 500 Ω
External 24V : 1050 Ω
Photo-Isolation 3750 Vrms
Intra-module Isolation, Field to Logic 3000 VDC
Interface
Interface RS-485
Format N, 8, 1
Baud Rate 1200 ~ 115200 bps
LED Indicators
1 LED Power/Communication indicator
Power
Input +10 ~ +30 VDC
Power Consumption 3.0 W
Omgeving
Operating Temperature -25 °C ~ +75 °C
Storage Temperature -40 °C ~ +85 °C
Humidity 5 ~ 95% RH, non-condensing
