ICPDAS I-7021

Levertijd:

2~7 dagen

SKU

I-7021

1-channel 12-bit Analog Output Module

● Resolution: 12-bit
● Analog output type: mA,
● Output Range: 0 ~ 20 mA, 4 ~ 20 mA, 0 ~ 10 V
● Accuracy: ±0.1%
● Programmable Output Slew Rate: 0.0625 ~ 512 V/sec. 0.125 ~ 1024 mA/sec.
● Dual Watchdog

Details

I-7000 is a family of network data acquisition and control modules. They provide analog-to-digital, digital-to-analog, digital input/output, timer/counter and other functions. These modules can be remote controlled by a set of commands.

The ICPDAS Analog Output Module I-7021 provides cost-effective protection and conditioning for a wide range of valuable industrial control signals and systems.

The DCON utility can help users to configure and test I-7021 output modules. Plenty of library functions and demo programs are provided to let users develop programs easily under Windows, Linux and DOS operating systems Users may mount the modules on a DIN-Rail, panel or wall. Modules have a screw-terminal block to connect to the signals.

SPECIFICATIES

Meer informatie

Art.nr.

I-7021

Fabrikant

ICPDAS

Analog Output

Output Channels

Output Type

0 ~ 20 mA , 4 ~ 20 mA and 0 ~ 10 V

Resolution

12-bit
