ICPDAS X520
Levertijd:
2~7 dagen
SKU
X520
4-port RS-232 (3-Pin), 1-ch D/I and 2-ch D/O
Supported Products:
I-7188XB/XG/EX/EG, μPAC-7186EX/PEX/EG/EX-FD/EX-SM
Expansion boards for RS-232/422/485, DI, DO
The X520 provides 4 non-isolated RS-232 serial ports, 1 digital input channel and 2 digital output channels. It equips 16 bytes hardware FIFO for each port, offers speed up to 115.2K bps and supports full-duplex communication.
Meer informatie
Art.nr.
X520
Fabrikant
ICPDAS
Algemeen
| Number of Ports | 4 | ||||||
| Interface | TxD, RxD, GND | ||||||
| Controller |
|
||||||
| Bus | Parallel I/O Module | ||||||
| Connector | 14-Pin Removable Terminal Block | ||||||
| Isolation Voltage | Non-isolated |
Software
| Support interrupt driven software library |
| Support VxCOM library |
Digital Input
| Input Channels | 1 |
| Input Type | Source, Dry |
| On Voltage Level | +1 VDC max or connect to GND |
| Off Voltage Level | +3.5 V ~ +30 VDC or Open |
| Isolation Voltage | Non-isolated |
Digital Output
| Output Channels | 2 |
| Output Type | Open-collector (Sink) |
| Stop Bit | +5 ~ +30 VDC |
| Max. Load Current | 100 mA/channel |
| Isolation Voltage | Non-isolated |
Specifications
| Power Requirement | +5 VDC |
| Dimensions | 64 x 38mm |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
