ICPDAS X324
Levertijd:
2~7 dagen
SKU
X324
4-channel D/A (0 ~ 5V) add 4-channel D/O board for I-7188XB/XG/EX/EG, μPAC-7186XB/XG/EX/EG-FM/SM/SD/FD
D/A boards on 40MHZ CPU the throughput rate is 900 samples/second max.
Meer informatie
Art.nr.
X324
Fabrikant
ICPDAS
Analog Output
| Output Channels | 4 |
| Output Type | 0 ~ +5 V |
| Resolution | 12-bit |
| Output Capacity | 20mA |
| Isolation Voltage | Non-isolation |
Digital Output
| Output Channels | 4 |
| Output Type | Open-Collector (NPN) |
| Load Voltage | +30VDC, max. |
| Load Current | 100mA, max. |
| Isolation Voltage | Non-isolation |
Specifications
| Power Requirement | +5VDC |
| Dimensions | 64 x 38mm |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +80 °C |
| Humidity | 5% to 90% Non-condensing |
