CAN-2088D

CAN bus Remote I/O module with CANopen Protocol of 8-Channel PWM and 8-Channel High Speed Counter

● Hardware-controlled PWM output
● PWM output frequency: 0.2 Hz ~ 500 kHz with 0.1%~99.9% duty cycle
● PWM Output Modes: software trigger / hardware trigger
● Trigger each PWM output individually or all PWM outputs synchronously
● Support Burst output mode and Continue output mode
● Provide 32-bit 500 kHz high-speed counter for each DI channel
● Pass the validation of DeviceNet conformance test
● Provide EDS file for DeviceNet master interface

Brochure EN

Details

PWM (Pulse width modulation) is a powerful technique for controlling analog circuits. It uses digital outputs to generate a waveform with variant duty cycle and frequency to control analog circuits. CAN-2088D is a PWM slave module of DeviceNet protocol. It has 8 PWM output channels and 8 high speed counter channels. It can be used to develop powerful and cost effective analog control system.

APPLICATIONS:

● Controlling the position/speed of motors
● Dimming the brightness of lamps
● Controlling the speed of fans
● High speed counter

SPECIFICATIES

Meer informatie

Art.nr.

CAN-2088D

Fabrikant

ICPDAS

DeviceNet Interface

DeviceNet Specification

Volume I, Release 2.0 & Volume II, Release 2.0, Errata5

DeviceNet Subscribe

Group 2 Only Server

Connection Supported

1 connection for Explicit Messaging

1 connection for Polled I/O

1 connection for Bit-Strobe I/O

Baud Rate

125 kbps, 250 kbps, 500 kbps

Node ID

0 ~ 63

Heartbeat Message

Yes

Shutdown Message

Yes

Terminator Resistor

Switch for 120 Ω terminator resistor

Connector

5-pin screwed terminal block

(CAN_GND, CAN_L, CAN_SHLD, CAN_H, CAN_V+)

EDS File

Yes

PWM

Channels	8 (Source)
Frequency	0.2 ~ 500 kHz (non-continuous)
Scaling Resolution	16-bit (1 ~ 128 μs for each step)
Duty Cycle	0.1 ~ 99.9 %
PWM Mode	Burst mode, Continuous mode
Burst Mode Counter	1 ~ 65535 counts
Trigger Mode	Hardware (Start and Stop) or Software (Start and Stop)
Intra-module Isolation	3750Vrms
ESD Protection	4kV Contact for each channel

Digital Input

Channels	8 (Sink/Source)
On Voltage Level	5.5 ~ 30V
Off Voltage Level	<3.5V
Counter Frequency	500 kHz max.
Max. Counts	32-bits (4.294.967.295)
Input Impedance	4.7 kΩ, 1/4W
Intra-module Isolation	3750Vrms
ESD Protection	4kV Contact for each channel

LED Indicators

DeviceNet Status	3 LEDs for PWR/NET/MOD
Terminal Resister	1 LED as Terminal Resister indicators
PWM LED	8 LEDs as PWM Output indicators
DI LED	8 LEDs as Digital Input indicators
