ICPDAS CAN-2057D
Levertijd:
2~7 dagen
SKU
CAN-2057D
DeviceNet Module of 16-channel Isolated Open Collector Digital Output
● DeviceNet general I/O slave devices
● Group 2 Only Server (non UCMM-capable)
● Support Predefined Master/Slave Connection Set
● Connection supported (1 connection for Explicit Messaging, 1 connection for Polled I/O, 1 connection for Bit-Strobe I/O connection)
● Support DeviceNet heartbeat and shutdown messages
● Provide EDS file for DeviceNet master interface
● Support Application: Drive Relay, Resistance Load
● ESD Protection 4 kV Contact for each channel
DeviceNet is one kind of the network protocols based on the CAN bus and mainly used for the embedded network of the machine control, such as industrial machine control , aircraft engines monitoring, factory automation, medical equipments control, remote data acquisition, environmental monitoring, and packaging machines control, etc.
The CAN-2057D follows DeviceNet specification Volume I/II, Release 2.0. User can access the digital output status and set the configuration via DeviceNet EDS file. The CAN-2057D has 16 Digital output channels with Open Collector output type and can be used to develop powerful and cost effective digital control system.
By owing to the DeviceNet masters of ICP DAS, you can quickly build a DeviceNet network to approach your requirements. For more information about the DeviceNet master interfaces and other DeviceNet products, please refer to the following web site.
APPLICATIONS:
● Alarm detector
● Switch detection
Meer informatie
Art.nr.
CAN-2057D
Fabrikant
ICPDAS
DeviceNet Interface
| DeviceNet Specification | Volume I, Release 2.0 & Volume II, Release 2.0, Errata5 | |||
| DeviceNet Subscribe | Group 2 Only Server | |||
| Connection Supported |
|
|||
| Baud Rate | 125 kbps, 250 kbps, 500 kbps | |||
| Node ID | 0 ~ 63 | |||
| Heartbeat Message | Yes | |||
| Shutdown Message | Yes | |||
| Terminator Resistor | Switch for 120 Ω terminator resistor | |||
| Connector |
|
|||
| EDS File | Yes | |||
| LED | PWR/NET/MOD |
Digital Output
| Channels | 16 (Sink) |
| Load Voltage | +5 ~ +30 VDC |
| Output Max Load Current | 100 mA per channel |
| Output Type | Open Collector |
| Intra-module Isolation | 3750 Vrms |
| ESD Protection | 4 kV Contact for each channel |
LED Indicators
| DeviceNet Status | 3 LEDs for PWR/NET/MOD |
| Terminal Resister | 1 LED as terminal resister indicators |
| DO LED | 16 LEDs as digital output indicators |
Power
| Power Supply | Unregulated +10 ~ +30 VDC |
| Power Consumption | 1.5 W |
Mechanical
| Installation | DIN-Rail Mounting |
| Dimensions (w x l x h) | 32.3 x 99 x 77.5mm |
Omgeving
| Operating Temperature | -25 °C ~ 75 °C |
| Storage Temperature | -30 °C ~ 80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
