ICPDAS FR-2024iT
Levertijd:
2~7 dagen
SKU
FR-2024iT
4-channel Isolated Analog Output Module
● Built-in wire-saving FRnet control
● High-speed transmission reliability
● Simple synchronization mechanism
● No software overhead on protocol processing
● Supporting broadcasting (1:n data transmission)
● Duplicating output easily
● Fixed I/O scan-time and I/O synchronization
● DIN-Rail mountable
The FR-2024iT is a 12-bit, 4-ch analog outputs module that provides programmable output range (0 ~ + 10 VDC, -10 VDC ~ +10 VDC, 0 ~ +5 VDC, -5 VDC ~ +5 VDC, 0 ~ +20mA, +4mA ~ +20mA) . There are options for power on value and Safe Value for your consideration. It also has 240Vrms high over voltage protection for all analog outputs.
The FR-2000 I/O module has an FRnet interface. The users can daisy chain several FR-2000 modules together. Via FRnet, the FR-2000 modules can extend the remote I/O control of PC, PAC and PLC easily. Further information about the networking of FR-2017iT/2024iT; refer to literatures related to I-7188EF, I-8172W, and FRB-100/200/200U.
The FR-2000 I/O module has an FRnet interface. The users can daisy chain several FR-2000 modules together. Via FRnet, the FR-2000 modules can extend the remote I/O control of PC, PAC and PLC easily. Further information about the networking of FR-2017iT/2024iT; refer to literatures related to I-7188EF, I-8172W, and FRB-100/200/200U.
Meer informatie
Art.nr.
FR-2024iT
Fabrikant
ICPDAS
Analog Output
| Output Channels | 4 | ||||
| Output Type | 0~20mA, 4~20mA, 0~5V, +/-5V, 0~10V, +/-10V | ||||
| Resolution | 12-bit | ||||
| Accuracy | ±0.1% of FSR | ||||
| Zero Drift |
|
||||
| Span Drift | ±20ppm/°C | ||||
| DA Output Response Time | 10ms per channel | ||||
| Programmable Output Slope |
|
||||
| Voltage Output Capability | 10 V@20 mA | ||||
| Current Load Resistance | External +24V: 1050Ω | ||||
| Power-Up and Safe Value | Yes |
Interface
| Isolation Voltage | 2500 VDC | ||
| 2-wire Cabling |
|
||
| Transfer Distance |
|
||
| LED Indicators | Power, Communication Run, Communication Error, Terminal resistor, Digital output | ||
| Transfer Speed |
|
||
| Cyclic Scan Time |
|
EMS Protection
| ESD (IEC 61000-4-2) |
|
||
| EFT (IEC 61000-4-4) | 4 kV for power liner | ||
| Surge (IEC 61000-4-5) | 3 kV for power liner |
Power
| Input Voltage Range | +10 ~ +30 VDC (Non-isolation) |
| Power Consumption | 2.88 W Max. |
| Connector | 5-Pin Removable Terminal Block |
Mechanical
| Casing | Plastic |
| Flammability | UL 94V-0 materials |
| Dimensions (w x h x d) | 32.5 x 110 x 102mm |
| Installation | DIN-Rail |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +85 °C |
| Humidity | 10% ~ 90% non-condensing |
